8LSC55.ee030ffgg-4 | B&R 22.4 Nm Servo Motor

Introduction to the B&R 8LSC55.ee030ffgg-4

When your application demands precise positioning and dynamic performance, the 8LSC55.ee030ffgg-4 from B&R stands ready. This three-phase synchronous servo motor, part of the 8LSC series, is engineered for excellence. It offers a compact design and reduced weight, making it ideal for modern machinery. You get excellent dynamic characteristics and high positioning accuracy. This motor is a reliable choice for your automation needs.

Key Features and Technical Specifications

The 8LSC55.ee030ffgg-4 is packed with features that enhance performance and reliability. Its permanent-magnet design ensures efficient operation. The motor is externally fan-cooled, which helps maintain optimal temperatures. Let's look at the core specifications:

• Nominal speed: 3000 rpm
• Nominal torque: 22.4 Nm
• Nominal power: 7043 W
• Nominal current: 13.8 A
• Stall torque: 27.3 Nm
• Stall current: 16.8 A
• Maximum torque: 60.0 Nm
• Maximum current: 53.0 A
• Maximum speed: 5000 rpm
• Torque constant (KT): 1.63 Nm/A
• Voltage constant (KE): 98.44 V/1000rpm
• Stator resistance: 0.520 Ohm
• Stator inductance: 7.1 mH
• Moment of inertia: 12.9 kg·cm²
• Mass (without brake): 1.00 kg

These specs show a motor built for high performance. The large overload capacity is a standout feature. It allows the motor to handle peak demands without issue. This makes it suitable for challenging applications.

Applications and Use Cases

The 8LSC55.ee030ffgg-4 excels in various industrial settings. Its high torque and speed make it perfect for packaging machinery. You can also use it in material handling systems. The motor's precision supports robotics and assembly lines. Furthermore, its compact size fits well where space is limited. This motor helps improve productivity and efficiency in your operations.

Installation and Setup

Proper installation is key to getting the best performance. The motor features a single-cable (hybrid) solution option. This simplifies wiring and reduces setup time. It uses built-in plug-in connectors for easy integration. The motor is compatible with ACOPOS servo drives, specifically the 024X model. Always follow the manufacturer's guidelines for mounting and connection. This ensures safe and reliable operation.

Maintenance and Reliability

Reliability is crucial for minimizing downtime. The 8LSC55.ee030ffgg-4 is designed with durability in mind. Its externally fan-cooled design helps maintain consistent performance. The motor conforms to EN 60034-1 S1 continuous operation. It also meets insulation class F standards. Regular inspection of the motor and fan is recommended. This helps identify any potential issues early. Following the manual's maintenance schedule extends the motor's life.

Compatibility and Integration

Integrating this motor into your system is straightforward. It works seamlessly with B&R ACOPOS drives. The motor offers multiple feedback options, including resolver and EnDat. EnDat versions support functional safety features. The single-cable solution reduces cabling complexity. This integration capability makes it a versatile choice. You can easily upgrade existing systems with this motor.

Troubleshooting and Common Issues

Like any precision equipment, the motor may encounter issues. Common problems include overheating or unusual noise. Overheating can result from inadequate cooling. Ensure the fan is clean and operational. Noise may indicate bearing wear. Check the bearings periodically. If you face persistent issues, consult the official B&R documentation. Alternatively, contact Petro Auto Tech for expert assistance.

FAQ about the 8LSC55.ee030ffgg-4

Q: What is the nominal torque of the 8LSC55.ee030ffgg-4?

A: The nominal torque is 22.4 Nm.

Q: What is the maximum speed of this motor?

A: The maximum speed is 5000 rpm.

Q: Does the motor support functional safety encoders?

A: Yes, EnDat versions are available with safety-related variants.

Q: What is the recommended servo drive for this motor?

A: The recommended ACOPOS servo drive is the 024X model.

Product Support and Availability

The 8LSC55.ee030ffgg-4 is available through Petro Auto Tech. We are a trusted supplier of industrial automation parts. Contact us for pricing and availability. We ensure fast delivery and reliable service. Please verify current lifecycle status with us before ordering.
