170INT11001 | Schneider Modicon Momentum INTERBUS-S Adapter

Introduction to the 170INT11001

When your industrial network demands reliable communication between controllers and I/O modules, the 170INT11001 from Schneider Electric delivers a robust solution. As part of the Modicon Momentum series, this communication adapter is engineered to facilitate seamless connectivity using the INTERBUS-S protocol.

Designed specifically for use with Momentum I/O bases, the 170INT11001 ensures that your automation system operates with minimal downtime. Its support for ring topology enhances network flexibility and data reliability, making it a dependable choice for modern industrial environments.

Key Features and Technical Specifications

The 170INT11001 is built to perform under demanding conditions. Below are the core specifications that define its capabilities:

• Communication Protocol: INTERBUS-S
• Compatible Modules: Momentum I/O bases
• Topology Support: Ring topology
• Transmission Medium: Twisted pair cable
• Data Transmission Rate: 500 kbps
• Operating Temperature Range: 0°C to 55°C
• Storage Temperature Range: -20°C to 60°C
• Maximum Altitude: 2000 meters
• Environment: No corrosive gases
• Weight: Approximately 0.45 kg (1 lb.)

One distinctive feature is its support for ring topology, which allows for redundant data paths. This means that if one segment of the network fails, data can still travel through the alternate path, significantly improving system reliability.

Applications and Use Cases

In manufacturing plants, the 170INT11001 is ideal for connecting remote I/O panels to a central controller. Its twisted pair cable transmission ensures stable data flow over moderate distances, while the 500 kbps rate is sufficient for most discrete and analog signals.

Furthermore, because it operates in environments free from corrosive gases, it is well-suited for clean industrial settings such as electronics assembly or pharmaceutical production. The adapter’s compact design and lightweight construction make it easy to integrate into existing cabinets.

Installation and Setup

Installing the 170INT11001 is straightforward. First, ensure that the adapter is mounted securely on a DIN rail or panel. Then, connect the twisted pair cable to the INTERBUS-S port, following the ring topology guidelines. Finally, configure the network settings to match your system’s addressing scheme.

Always refer to the Schneider Electric user manual for detailed wiring diagrams and configuration steps. Proper installation minimizes signal interference and ensures optimal performance.

Maintenance and Reliability

To maintain long-term reliability, inspect the 170INT11001 periodically for signs of wear or loose connections. Because it operates in a corrosive-free environment, the risk of degradation is low, but routine checks are still recommended.

Keeping the adapter within its specified temperature range will extend its service life. If the unit is stored, ensure it remains within the -20°C to 60°C storage limits to prevent damage.

Compatibility and Integration

The 170INT11001 is specifically designed for use with Momentum I/O bases, ensuring seamless integration with Schneider Electric’s Modicon Momentum platform. It supports the INTERBUS-S protocol, which is widely used in industrial automation networks.

When integrating this adapter, verify that your controller supports INTERBUS-S communication. This compatibility ensures that data exchange between the controller and I/O modules is efficient and error-free.

Common Questions About the 170INT11001

Q: What is the maximum data transmission rate of the 170INT11001?

A: The 170INT11001 transmits data at 500 kbps, which is suitable for most industrial I/O applications.

Q: Can the 170INT11001 be used in high-altitude installations?

A: Yes, it is rated for operation at altitudes up to 2000 meters.

Q: What type of cable is required for the 170INT11001?

A: It uses twisted pair cable, which helps reduce electromagnetic interference.

Q: Is the 170INT11001 compatible with all Momentum I/O bases?

A: It is designed for use with Momentum I/O bases, but always verify compatibility with your specific base model.

Q: What is the operating temperature range for the 170INT11001?

A: It operates from 0°C to 55°C, making it suitable for most industrial environments.

Product Support and Availability

The 170INT11001 is available through Petro Auto Tech, an industrial automation parts supplier. Contact Petro Auto Tech for current pricing and lead times. In many cases, the unit is in stock and ready to ship.
