Introducing the Schneider 170AEC92000 High-Speed Counter Module
Petro Auto Tech now stocks the Schneider Electric Modicon 170AEC92000, a high-speed counter module base designed for the Modicon Momentum automation platform. This versatile module provides reliable performance for a wide range of industrial counting and positioning applications.
Engineered for durability, the 170AEC92000 includes TC (Tropicalization Protection) to withstand challenging environmental conditions. It carries UL and CSA certifications, confirming its adherence to rigorous safety and quality standards.
Key Technical Specifications and Capabilities
The 170AEC92000 offers six discrete inputs and four discrete outputs, organized into two groups of three inputs and two groups of two outputs. It supports positive logic for both inputs and outputs, with a discrete output voltage of 24V DC.
Input overvoltage protection handles surges up to 45V for 10 seconds, safeguarding the module. The voltage state is guaranteed ON at 11V or above and OFF at 5V or below, while current state is guaranteed ON at 2.5 mA or above and OFF at 1.2 mA or below.
This module includes two counters with a resolution of 24 bits plus sign. It supports incremental up/down, quadrature, and absolute SSI counting input types, with counting frequencies up to 10 kHz for single-ended and 200 kHz for differential inputs.
Application Scenarios and Use Cases
The 170AEC92000 is ideal for high-speed counting in packaging, material handling, and machine control systems. Its ability to handle both single-ended and differential signals makes it suitable for connecting to various encoders and sensors.
In a typical manufacturing line, the module can monitor product counts, track conveyor positions, or control cut-to-length operations. The fast response time of less than 0.1 ms for outputs ensures precise timing in automated processes.
Customer Case Scenario
Consider a beverage bottling plant that needs to count bottles accurately at high speeds. By integrating the 170AEC92000 with its existing Momentum platform, the plant can achieve reliable counting and trigger precise rejection of underfilled bottles, reducing waste and improving efficiency.
Comparison with Similar Modules
Compared to standard digital I/O modules, the 170AEC92000 offers dedicated high-speed counting features. While a typical digital input module only reads on/off states, this module processes quadrature and SSI signals, providing position and velocity data directly.
Its dual-counter design allows simultaneous monitoring of two independent axes, a capability not found in basic I/O modules. The 24-bit resolution ensures high accuracy for demanding applications.
Company Strength and Supply Assurance
Petro Auto Tech specializes in providing genuine industrial automation parts, including the Schneider 170AEC92000. Our team ensures that every product meets quality standards and is available for prompt shipment.
With a focus on customer satisfaction, we offer competitive pricing and reliable support. Contact Petro Auto Tech today to inquire about the 170AEC92000 and other automation components.
Frequently Asked Questions About the 170AEC92000
What is the operating temperature range for the 170AEC92000?
The 170AEC92000 operates in ambient air temperatures from 32 to 140 °F (0 to 60 °C). It can be stored in temperatures from -40 to 185 °F (-40 to 85 °C).
Does the 170AEC92000 support differential encoders?
Yes, the module supports differential counting inputs with a voltage of 5V DC and a counting frequency up to 200 kHz. It also accepts single-ended 24V DC inputs up to 10 kHz.
What certifications does the 170AEC92000 hold?
The module is certified by UL and CSA, ensuring compliance with North American safety standards. It also carries CE marking for the European market.
How many counters are available on the 170AEC92000?
The 170AEC92000 includes two counters, each with a resolution of 24 bits plus sign. This allows for high-resolution counting and positioning tasks.
Conclusion and Outlook
The Schneider 170AEC92000 is a robust and flexible solution for high-speed counting applications. Its combination of inputs, outputs, and counter features makes it a valuable addition to any Modicon Momentum system.
As industrial automation continues to evolve, modules like the 170AEC92000 will remain essential for precise control and monitoring. Contact Petro Auto Tech to secure this component for your next project.
