171CCC96030C | Schneider Modicon Momentum Processor Adaptor 50 MHz

Introduction to the 171CCC96030C Processor Adaptor

When control systems demand reliable network communication and efficient data processing, the 171CCC96030C from Schneider Electric delivers. As a processor adaptor within the Modicon Momentum series, this component integrates an Ethernet port and operates at a clock frequency of 50 MHz, making it suitable for various control applications.

Engineered for clean indoor environments, the 171CCC96030C supports both I/O scanning and Modbus TCP messaging, ensuring seamless integration into existing automation architectures. Its compact design and robust performance make it a practical choice for engineers seeking dependable operation.

Key Features and Technical Specifications

• Processor adaptor for the Modicon Momentum automation platform.
• Integrated Ethernet port for network communications.
• Clock frequency of 50 MHz for efficient processing.
• Operating temperature range of 0 to 40 degrees Celsius.
• Storage temperature range of 0 to 50 degrees Celsius.
• Maximum operating and storage humidity of 80% RH without condensation.
• Operating altitude up to 1000 meters above sea level.
• Flash memory of 512 KB and RAM of 512 KB.
• Discrete I/O processor capacity of 8192 I/8192 O.
• Register I/O processor capacity of 26048 I/26048 O.

One distinctive feature is the 50 MHz clock frequency, which provides the processing power needed for demanding control tasks. This ensures responsive performance in real-time applications.

Applications and Use Cases

The 171CCC96030C is well-suited for industrial automation scenarios where reliable Ethernet communication and Modbus TCP messaging are essential. For example, in a manufacturing line, this processor adaptor can coordinate multiple I/O devices, ensuring efficient data exchange. Additionally, its support for I/O scanning enables seamless integration with remote I/O modules, reducing wiring complexity. Consequently, engineers can deploy this adaptor in various control systems, from material handling to process control.

Installation and Setup

When installing the 171CCC96030C, ensure the environment is clean and free from corrosive chemicals, as specified. Mount the adaptor on a Momentum I/O base, which supplies the required 5.0 V DC power. Verify that the operating temperature remains within 0 to 40 degrees Celsius to maintain optimal performance. Additionally, confirm that the altitude does not exceed 1000 meters above sea level. Finally, connect the Ethernet cable to the dedicated port for network communication.

Maintenance and Reliability

Regular inspection of the 171CCC96030C is recommended to ensure long-term reliability. Check for any signs of dust accumulation or moisture, as the unit is rated for up to 80% RH without condensation. Since the device is designed for clean indoor environments, avoid exposure to chemicals or extreme conditions. By following these simple practices, you can extend the service life of the processor adaptor and minimize downtime.

Compatibility and Integration

The 171CCC96030C is part of the Modicon Momentum family, ensuring compatibility with Momentum I/O bases and related components. It supports Ethernet communication and Modbus TCP messaging, allowing integration with Schneider Electric's Concept, Modsoft, and ProWORX software suites. Additionally, the adaptor is compatible with the Transparent Ready concept, Class B10, facilitating seamless network integration.

Troubleshooting and Common Issues

If communication issues arise, first verify that the Ethernet cable is securely connected and that the network settings match the requirements of your control system. Additionally, check that the power supply from the Momentum I/O base is stable at 5.0 V DC. If the adaptor does not respond, confirm that the operating temperature is within the specified range. For persistent problems, consult the official Schneider Electric documentation or contact Petro Auto Tech for technical support.

FAQ about 171CCC96030C

Q: What is the clock frequency of the 171CCC96030C?

A: The clock frequency is 50 MHz, providing efficient processing for control applications.

Q: Does the 171CCC96030C support Modbus TCP messaging?

A: Yes, Modbus TCP messaging is supported, enabling seamless network communication.

Q: What is the operating temperature range?

A: The operating temperature range is 0 to 40 degrees Celsius.

Q: How much memory does the 171CCC96030C have?

A: It includes 512 KB of flash memory and 512 KB of RAM.

Q: What is the supply voltage requirement?

A: The rated supply voltage is 5.0 V DC +/-5%, supplied by the Momentum I/O base.

Product Support and Availability

The 171CCC96030C is available from Petro Auto Tech, an industrial automation parts supplier. In stock and ready to ship, this processor adaptor can be ordered with confidence. For further assistance, contact Petro Auto Tech to verify current lifecycle status and availability.
