171CCC98020 | Schneider Modbus Ethernet Processor Adaptor Module

Introduction to the 171CCC98020 Processor Adaptor Module

When industrial networks demand reliable communication, the 171CCC98020 from Schneider Electric delivers. This processor adaptor module is part of the Modicon Momentum series, engineered to facilitate robust data exchange. It supports both Ethernet and Modbus protocols, making it a versatile choice for diverse automation environments.

Built-in RAM ensures efficient processing, while the CE mark confirms compliance with applicable standards. With a compact design weighing just 0.19 lbs (0.09 kg), this module integrates easily into existing control panels.

Key Features & Technical Specifications

• Manufacturer: Schneider Electric
• Product Type: Processor Adaptor Module
• Product Line: Modicon Momentum
• Part Number: 171CCC98020
• Weight: 0.19 lbs (0.09 kg)
• Communication Adaptor: Yes
• Ethernet: Supported
• Modbus: Supported
• RAM: Included
• CE Marked: Yes
• Operating Temperature: 0 to 40 degrees Celsius
• Maximum Operating Altitude: 1000 meters above sea level without derating
• Maximum Operating Humidity: 80% RH without condensation
• Maximum Storage Humidity: 80% RH without condensation

One distinctive feature is the dual-protocol support. By combining Ethernet and Modbus in a single module, the 171CCC98020 simplifies network architecture and reduces the need for additional converters. This can lower installation costs and improve system reliability.

Real-World Applications

In manufacturing plants, the 171CCC98020 connects programmable logic controllers to supervisory systems. Its Ethernet capability enables fast data transfer for real-time monitoring. Meanwhile, Modbus support ensures compatibility with legacy equipment, bridging old and new technologies seamlessly.

For example, a food processing line can use this module to link sensors and actuators to a central control room. The robust communication ensures consistent product quality and reduces downtime.

Installation & Setup

Mounting the 171CCC98020 is straightforward. It fits into standard DIN rail or panel configurations typical of the Modicon Momentum series. Ensure proper grounding and follow Schneider's guidelines for wiring. The module's lightweight design simplifies handling during installation.

Before powering up, verify that the operating environment stays within the specified temperature and humidity ranges. This prevents performance degradation and extends the module's lifespan.

Maintenance & Reliability

Regular inspection of the 171CCC98020 helps maintain reliable operation. Check for dust accumulation on connectors and ensure ventilation is unobstructed. The module's ability to operate at up to 80% relative humidity without condensation makes it suitable for humid industrial settings.

Periodic testing of communication links can identify potential issues early. Following the manufacturer's maintenance manual ensures long-term dependability.

Compatibility & Integration

The 171CCC98020 integrates with Schneider Electric's Modicon Momentum ecosystem. It supports Ethernet and Modbus protocols, allowing connection to a wide range of PLCs, HMIs, and SCADA systems. This flexibility simplifies system design and expansion.

Troubleshooting Common Issues

If communication errors occur, first check network cabling and connections. Verify that the module is receiving power and that all indicators are normal. Consult the official Schneider documentation for detailed diagnostics.

For persistent issues, contact Petro Auto Tech for technical support. Our team can help identify compatibility problems or configuration errors.

Frequently Asked Questions

Q: What communication protocols does the 171CCC98020 support?

A: The 171CCC98020 supports Ethernet and Modbus protocols, as specified in its technical data.

Q: What is the operating temperature range for this module?

A: The module operates from 0 to 40 degrees Celsius, ensuring reliable performance in typical industrial environments.

Q: Is the 171CCC98020 CE marked?

A: Yes, the 171CCC98020 carries the CE mark, indicating compliance with applicable European directives.

Q: Does the module include RAM?

A: Yes, the 171CCC98020 includes built-in RAM to support efficient processing.

Q: What is the maximum operating altitude without derating?

A: The module can operate at altitudes up to 1000 meters above sea level without derating.

Product Support & Availability

The Schneider 171CCC98020 is available from Petro Auto Tech, an industrial automation parts supplier. We ensure prompt shipping and reliable customer service. Contact us for current stock and delivery options.
