190501-11-00-00 | Bently Nevada 100 mV/in/s Velocity Transducer

Why Choose the Bently Nevada 190501-11-00-00 Velomitor CT?

When rotating machinery demands precise vibration measurement, the 190501-11-00-00 from Bently Nevada provides a dependable solution. This Velomitor CT velocity transducer is engineered for industrial environments where accuracy and durability are non-negotiable. Its robust 316L stainless steel case and MIL-C-5015 connection interface ensure long-term performance in harsh conditions.

With a sensitivity of 3.94 mV/mm/s (±5%), this transducer delivers consistent output for predictive maintenance programs. The frequency response of 3.0 Hz to 900 Hz (±1.0 dB) covers typical machine vibration ranges, making it suitable for fans, pumps, and motors. Additionally, the transducer's internal electronics are isolated from the case, reducing ground loop issues.

Key Features and Technical Specifications

The 190501-11-00-00 is designed for reliable operation across a wide temperature range. Below are the critical specifications that define its performance:

• Sensitivity: 3.94 mV/mm/s (100 mV/in/s) ±5%
• Frequency Response: 3.0 Hz to 900 Hz (180 to 54,000 cpm) ±1.0 dB; 1.5 Hz to 1.0 kHz (90 to 60,000 cpm) ±3.0 dB
• Output Bias Voltage: 10.1 Vdc ± 1.0 Vdc, Pin A referenced to Pin B
• Dynamic Output Impedance: <400 Ω typical
• Broadband Noise: 0.229 mm/s (0.009 in/s) pk
• Base Strain Sensitivity: 0.43 mm/s/μstrain (0.017 in/s/μstrain)
• Maximum Cable Length: 305 metres (1,000 ft.) of cable (part number 02173006) with no signal degradation
• Operating Temperature: -40°C to +85°C (-40°F to +185°F)
• Storage Temperature: -40°C to +100°C (-40°F to +212°F)
• Shock Limit: 5000 g pk, maximum
• Humidity Limit: 100% condensing, non-submerged
• Magnetic Field Susceptibility: <0.0068 mm/s/gauss (0.268 mil/s/gauss) @ 50 gauss, 50-60 Hz
• Weight: <297 g (10.5 oz.), typical
• Case Material: 316L stainless steel
• Connector: 2-pin 316L stainless steel MIL-C-5015, top
• Mounting Torque: 4.5 N-m ± 0.6 N-m (40 in-lbf ± 5 in-lbf)

These specifications ensure accurate vibration data collection, which is essential for condition monitoring and predictive maintenance strategies.

Applications and Use Cases

The 190501-11-00-00 is ideal for monitoring rotating equipment such as turbines, compressors, and electric motors. Its wide frequency response and high shock tolerance make it suitable for both steady-state and transient vibration analysis. For example, in a petrochemical plant, this transducer can detect early bearing wear, preventing unplanned downtime. Moreover, its rugged construction allows installation in harsh environments, including high-humidity areas.

Installation and Setup

Proper installation is critical for accurate measurements. The transducer mounts via a 1/4-28 stud (as per the mounting hardware option) and requires a mounting torque of 4.5 N-m ± 0.6 N-m. Ensure the mounting surface is clean and flat to achieve optimal frequency response. The MIL-C-5015 connector provides a secure, weatherproof connection, and the internal ground isolation simplifies wiring in systems with potential ground loops.

Maintenance and Reliability

Regular inspection of the transducer and its cabling is recommended to maintain reliable operation. Check for physical damage, loose connections, and signs of corrosion. The 316L stainless steel case resists rust, extending service life. Since the transducer has no moving parts, it requires minimal maintenance, reducing total cost of ownership. For long-term reliability, verify the output bias voltage periodically to ensure the internal electronics are functioning correctly.

Compatibility and Integration

The 190501-11-00-00 is compatible with Bently Nevada vibration monitoring systems that accept velocity transducer inputs. Its standard MIL-C-5015 connection interface allows easy integration with existing cabling. The transducer's low output impedance (<400 Ω) ensures signal integrity over long cable runs, up to 305 meters, making it suitable for large facilities.

Frequently Asked Questions

Q: What is the sensitivity of the 190501-11-00-00?

A: The sensitivity is 3.94 mV/mm/s (100 mV/in/s) ±5%, ensuring accurate velocity measurement.

Q: Can the transducer be used in hazardous areas?

A: The 190501-11-00-00 with agency approval option 00 has no approvals. For intrinsically safe versions, refer to options 01 through 04, which include Ex ia IIC T4 ratings.

Q: What is the maximum cable length?

A: The maximum cable length is 305 meters (1,000 feet) using cable part number 02173006, with no signal degradation.

Q: What is the operating temperature range?

A: The operating temperature range is -40°C to +85°C (-40°F to +185°F), suitable for most industrial environments.

Q: How should the transducer be mounted?

A: Mount the transducer using a stud (1/4-28) with a torque of 4.5 N-m ± 0.6 N-m. Ensure the mounting surface is clean and flat.

Product Support and Availability

The 190501-11-00-00 is available from Petro Auto Tech, an industrial automation parts supplier. For pricing and lead time, contact our sales team. We offer fast shipping and reliable customer support to help you integrate this transducer into your monitoring system.
