200151-60-03-10 | Bently Nevada 6.0m Accelerometer Standard Cable

Introduction to the 200151-60-03-10

When harsh industrial environments demand reliable vibration monitoring, the 200151-60-03-10 from Bently Nevada provides a robust connection. This accelerometer standard cable is designed to link transducers to monitoring systems with consistent signal integrity. Its 6.0-meter length offers flexibility for machinery installations where sensor placement requires a moderate cable run.

Key Features & Technical Specs

• Model: 200151 – Accelerometer Interface Standard Cable with connectors on both ends.
• Cable length: 6.0 meters (specified by -60 in part number).
• Armor option: 03 – Blue cable with armor for enhanced mechanical protection.
• Coupling nut: 10 – Enhanced coupling nut on both ends for better grip when tightening to the accelerometer.
• Minimum bend radius: 63.5 mm (2.5 in) to prevent cable damage during routing.
• Operating temperature range: -20 ºC to +100 ºC (-4 ºF to +212 ºF). Cables may be used at lower temperatures if not flexed or bent.
• Construction: 4-conductor, 22 AWG with braided shield and drain wire (85% coverage, minimum), PVC outer jacket, nickel-plated coupling nuts.
• Seal: Connectors provide an IP67 seal to transducers and mating hardware; connectors are molded to the cable.
• Connector protection: DC4 electrical insulating compound in connectors provides additional moisture protection during thermal shock.

A distinctive spec is the IP67 seal, which ensures the connection remains protected against dust and temporary water immersion—critical for rotating machinery in wet or washdown environments.

Applications & Use Cases

In predictive maintenance programs, the 200151-60-03-10 is commonly used to connect accelerometers on pumps, motors, fans, and compressors. Its armored jacket resists abrasion in cable trays or conduits. The enhanced coupling nuts simplify installation in tight spaces, reducing the risk of cross-threading. For example, in a petrochemical plant, this cable can reliably transmit vibration data from a critical pump to a Bently Nevada monitoring system, helping prevent unplanned downtime.

Installation & Setup

When installing the 200151-60-03-10, ensure the cable does not bend tighter than its 63.5 mm minimum bend radius. Route the cable away from sharp edges and excessive heat sources. Tighten the enhanced coupling nuts firmly by hand, then use a wrench for final seating—avoid over-torquing. For installations below -20 ºC, avoid flexing the cable to prevent damage. The IP67 seal is effective only when connectors are fully mated and the cable jacket is intact.

Maintenance & Reliability

Periodically inspect the cable for cuts, abrasions, or kinks, especially near connector ends. Verify that coupling nuts remain tight and that the IP67 seal is uncompromised. In high-vibration environments, secure the cable with clamps every 0.5-1 meter to reduce strain on connectors. Following these practices extends service life and maintains signal quality.

Compatibility & Integration

The 200151-60-03-10 is designed for Bently Nevada accelerometers and compatible monitoring hardware. It uses a 4-conductor, 22 AWG shielded cable suitable for dynamic signal transmission. Always verify connector types match your transducer and monitor before ordering.

Frequently Asked Questions

Q: What is the exact length of the 200151-60-03-10 cable?

A: The cable length is 6.0 meters, as indicated by the -60 option in the part number.

Q: Does the cable include armor?

A: Yes, the 03 armor option provides a blue cable with armor for added mechanical protection.

Q: What is the operating temperature range?

A: The cable operates from -20 ºC to +100 ºC (-4 ºF to +212 ºF). Avoid flexing below -20 ºC.

Q: What type of connectors does the cable use?

A: The cable has connectors on both ends with enhanced coupling nuts (option 10) for a secure grip.

Q: Is the connector seal rated for wet environments?

A: Yes, the connectors provide an IP67 seal when mated, and DC4 insulating compound adds moisture protection during thermal shock.

Product Support & Availability

The 200151-60-03-10 is available from Petro Auto Tech. Please verify current lifecycle status and availability before ordering. Our team can assist with compatibility questions and expedited shipping options.
