200157-06-05 | Bently Nevada 10.2 mV/(m/s²) Enveloping Trendmaster Pro Accelerometer

What Makes the 200157-06-05 Essential for Bearing Protection?

When unexpected bearing failures threaten production uptime, the 200157-06-05 Bently Nevada Enveloping Trendmaster Pro Accelerometer provides early warning. This sensor detects subtle vibration signatures from roller element bearings and cavitation effects, helping maintenance teams act before catastrophic damage occurs. With a sensitivity of 10.2 mV/(m/s²) at 80 Hz, it captures critical data for predictive maintenance programs.

Key Features & Technical Specs of the 200157-06-05

• Sensitivity: 10.2 mV/(m/s²) (100 mV/g) at 80 Hz, ±12%.
• Measurement Range: ±245 m/s² (±25 g) for acceleration.
• Frequency Range: 10 to 10,000 Hz (600 to 600,000 cpm), referenced to 80 Hz.
• Mounted Resonant Frequency: Greater than 20 kHz (>1200 kcpm).
• Amplitude Linearity: ±2% from 1 to 10 g peak.
• Transverse Sensitivity: ≤7%.
• Excitation Voltage: 4.7 to 5.5 Vdc.
• Output Bias Voltage: +2.5 ± 0.23 Vdc.
• Quiescent Current: Less than 800 µA.
• Temperature Range: -40 °C to +105 °C (-40 °F to +221 °F).

A standout feature is the enveloping channel type, which extracts low-energy impact signals from background noise. This makes the 200157-06-05 ideal for detecting early-stage bearing defects that standard accelerometers might miss.

Real-World Applications for the 200157-06-05

Engineers rely on the 200157-06-05 in rotating machinery monitoring, particularly for roller element bearings and cavitation effects in pumps. Its rugged design withstands harsh industrial environments, including 100% condensing humidity and axial shock up to 49,050 m/s² pk (5,000 g pk). The ceramic shear sensing element ensures stable performance over time.

Installation Guide for the 200157-06-05 Accelerometer

Mount the 200157-06-05 using the 3/8-24 female thread with a mounting torque of 2.7 to 6.8 N·m (2 to 5 ft·lbf). The stud option 06 provides a 3/8-24 to 1/4 NPT adapter with a 3/4 inch hex. Ensure the mounting surface is clean and flat for optimal frequency response. Allow 24 hours cure time if adhesive mounting is used.

Maintenance & Reliability of the 200157-06-05

Routine inspection of the 200157-06-05 involves checking cable integrity and connector tightness. The hermetically sealed 316L stainless steel housing protects against moisture and contaminants. With proper installation, the sensor delivers consistent data over long service intervals, reducing total cost of ownership.

Compatibility & Integration

The 200157-06-05 works with Bently Nevada ProTIM options for standard acceleration-to-velocity with acceleration enveloping. It outputs a positive-going signal (SIG+ positive with respect to SIG-) and requires 4.7 to 5.5 Vdc excitation. For system integration, refer to the official Bently Nevada documentation.

Frequently Asked Questions about the 200157-06-05

Q: What is the sensitivity of the 200157-06-05?

A: The sensitivity is 10.2 mV/(m/s²) (100 mV/g) at 80 Hz, with a tolerance of ±12%.

Q: What is the temperature range for the 200157-06-05?

A: The operating temperature range is -40 °C to +105 °C (-40 °F to +221 °F).

Q: What approvals does the 200157-06-05 have?

A: It carries multiple approvals including CSA, ATEX, and IECEx.

Q: What is the mounting thread size for the 200157-06-05?

A: The mounting thread is 3/8-24 female, with a stud option of 3/8-24 to 1/4 NPT.

Product Support & Availability

The 200157-06-05 is available from Petro Auto Tech. Please verify current lifecycle status and availability with Petro Auto Tech before ordering. Our team can assist with technical inquiries and expedited shipping.
