31000-28-05-00-012-01-02 | Bently Nevada 8 mm Probe Housing

Introduction to the 31000-28-05-00-012-01-02

When you need dependable vibration monitoring in demanding industrial settings, the 31000-28-05-00-012-01-02 from Bently Nevada delivers. This 31000 Proximity Probe Housing is engineered to protect a 3300 XL 8 mm probe, ensuring accurate readings even under stress. With its rugged construction and multiple approvals, it suits rotating machinery applications where uptime is critical.

Key Features and Technical Specifications

The 31000-28-05-00-012-01-02 offers a robust design that stands up to harsh conditions. Its housing is made of glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic with conductive fibers, providing both strength and electrostatic dissipation. The sleeve and retaining chain use AISI 304 stainless steel, while the outer sleeve and exterior screws are AISI 303 stainless steel for corrosion resistance. A Neoprene O-ring ensures a reliable seal.

• Probe option: 3300 XL 8 mm probe with multiple approvals
• Cable length: 0.5 metre (20 inches)
• No standoff adapter included
• Probe penetration: 1.2 inches
• Fittings: one 3/4-14 NPT fitting and two plugs
• Mounting thread: 3/4-14 NPT
• Temperature rating: -51°C to +105°C (-60°F to +221°F)
• Weight: 1.2 kg (2.6 lb)

This housing also carries a Type 4X rating certified by CSA, an IP66 rating verified by SC115582-1 (e) 106, and a CENELEC EN50014 rating for electrostatic dissipation in hazardous areas. The housing impact strength is certified by BASEEFA to withstand two separate 4 Joule impacts at extreme temperatures, and CSA verified a 7 Joule impact at room temperature.

Applications and Use Cases

In petrochemical plants, power generation facilities, and heavy machinery, the 31000-28-05-00-012-01-02 provides reliable protection for proximity probes. Its high ingress protection makes it suitable for outdoor or washdown environments. Moreover, the stainless steel components resist corrosion from chemicals and moisture, extending service life. For maintenance engineers, this housing simplifies probe installation and reduces the risk of damage during operation.

Installation and Setup

Mounting the 31000-28-05-00-012-01-02 is straightforward. The 3/4-14 NPT mounting thread fits standard ports, and the included fittings allow secure conduit connections. When installing, ensure the probe cable is routed without sharp bends to avoid stress. The recommended torque for the retaining nut is 29.4 N·m (260 in·lb), which helps maintain a proper seal and stable positioning. Always follow Bently Nevada's guidelines for probe gap and positioning to achieve accurate measurements.

Maintenance and Reliability

Regular inspection of the housing and O-ring helps maintain its protective rating. Check for signs of wear or damage, especially after extreme temperature cycles. Because the housing is designed to withstand high impacts, it offers long-term durability. By choosing the 31000-28-05-00-012-01-02, you reduce the frequency of replacements, lowering your total cost of ownership.

Compatibility and Integration

This housing is compatible with Bently Nevada 3300 XL 8 mm proximity probes, ensuring seamless integration with existing monitoring systems. The multiple approvals (CSA, CENELEC) allow use in various global regions. For systems that require a standoff adapter, note that this model does not include one, so plan accordingly.

Troubleshooting and Common Issues

If you experience signal loss, first check the cable connection and ensure the probe is properly seated. Verify that the mounting thread is tight and the O-ring is intact. In harsh environments, contamination can affect performance, so periodic cleaning of the exterior is recommended. For persistent issues, consult the Bently Nevada manual or contact Petro Auto Tech for assistance.

FAQ

What is the temperature range for the 31000-28-05-00-012-01-02?

The housing operates from -51°C to +105°C (-60°F to +221°F), making it suitable for extreme conditions.

Does this housing include a standoff adapter?

No, the standoff adapter option is 00, meaning no standoff adapter is included.

What probe does this housing work with?

It is designed for the 3300 XL 8 mm probe, which has multiple approvals.

What is the mounting thread size?

The mounting thread is 3/4-14 NPT, which is required if you order a standoff adapter.

Product Support and Availability

The 31000-28-05-00-012-01-02 is available through Petro Auto Tech. We stock this item and can ship it promptly to minimize your downtime. Contact our team for current lead times and ordering information.
