Allen-Bradley 1763-MM1 Memory Module for MicroLogix 1100 PLC

Product Overview

The 1763-MM1 is a memory module from Allen-Bradley. It belongs to the MicroLogix 1100 series. This module provides 128KB of non-volatile memory. It stores program data and recipe data. You can also use it to transfer programs between controllers. The memory does not need a battery to retain data. This prevents accidental program loss. The module supports write protection and program compare. You can remove and insert it under power (RIUP).

Application Scenarios

Use the 1763-MM1 in automation systems that require secure program backup. It works well in manufacturing lines. It is ideal for batch processing. The module helps transfer programs to new controllers quickly. Operators can store multiple recipes. This reduces downtime during changeovers. The non-volatile memory keeps data safe during power loss.

Technical Specifications

Manufacturer: Rockwell Automation. Brand: Allen-Bradley. Series: MicroLogix 1100. Product type: Memory module. Memory size: 128 KB. Memory type: Non-volatile. Compatible controllers: MicroLogix 1100. Recipe logging: Supported. Data logging: Not supported. Write protection: Supported. Program compare: Supported. Hot swapping (RIUP): Supported. The module does not increase the controller's built-in memory.

Installation & Maintenance Guide

To install the module, remove the port cover from the controller. Align the module with the mounting guides. Push gently until it clicks into place. If you feel resistance, pull back and try again. You can install the module with power on or off. The controller needs a power cycle to recognize the module. This module works with MicroLogix 1100 controllers only.

Packing List

1 x Allen-Bradley 1763-MM1 memory module. 1 x anti-static bag. No additional accessories included.
