Allen-Bradley 1769-IF16V 16-Point Analog Input Module

Product Overview

The Allen-Bradley 1769-IF16V is a 16-point analog input module. It is part of the Compact I/O family. This module works with CompactLogix systems. It accepts voltage signals only. The input range is ±10.5V DC. It uses a sigma-delta ADC for precise conversion. Resolution is 16 bits for unipolar signals. Bipolar signals get 15 bits of resolution. Accuracy is ±0.35% of full scale at 25°C. This module supports single-ended wiring. It includes channel diagnostics for over- or under-range conditions. The 1769-IF16V is a reliable choice for industrial automation.

Application Scenarios

This module is ideal for factory automation. Use it in manufacturing lines. It works well for process control. Monitor voltage signals from sensors. Connect to transducers or transmitters. It fits in control cabinets. The module mounts on a DIN rail. It also supports panel mounting. Use it in packaging machines. It is suitable for material handling. The 1769-IF16V works in harsh environments. Operating temperature ranges from 0 to 60°C. It handles humidity up to 95%.

Technical Specifications

Inputs: 16 single-ended. Voltage range: ±10.5V DC. Normal ranges: ±10V, 0-10V, 0-5V, 1-5V DC. ADC type: sigma-delta. Resolution: 16 bits unipolar, 15 bits bipolar. Accuracy drift: ±0.03% per °C. Nonlinearity: ±0.03%. Repeatability: ±0.06%. Module error: 1.0%. Backplane current: 1.4A at 24V. Power dissipation: 2.4W. Isolation voltage: 30V DC. Common mode rejection: 60 dB. Input impedance: 1 MOhm. Weight: 0.62 lb. Dimensions: 118 x 87 x 35 mm.

Installation & Maintenance Guide

Mount the module on a DIN rail. Use the provided mounting tabs. Connect using Belden 8761 shielded cable. Ensure wiring is single-ended. Power the module with compatible supplies. Use 1769-PA2, 1769-PB2, 1769-PA4, or 1769-PB4. Do not exceed 30V DC at terminals. Keep the module in a clean area. Check connections regularly. Replace if damage is visible. The module is open type. Do not use in hazardous locations. Follow all local safety codes.

Packing List

1 x 1769-IF16V Analog Input Module. 1 x Installation Manual. 1 x Mounting Tabs Kit. No additional cables included. Order cables separately. Use only recommended cables. Shipping via Fedex, UPS, or DHL. Contact us for bulk orders.
