Allen-Bradley 2097-V32PR4 Kinetix 300 Drive 1.70 kW

Product Overview

The Allen-Bradley 2097-V32PR4 is a Kinetix 300 Ethernet/IP Indexing Drive. It operates on single-phase 240V input power. This drive provides continuous output current of 8.0 A rms. It delivers a peak output current of 24.0 A rms. The unit includes an integrated AC line filter. It also features Safe Torque-Off for enhanced safety. This drive is ideal for precise motion control tasks. Its compact design saves panel space. The 2097-V32PR4 supports efficient indexing operations. It is a reliable choice for industrial automation.

Application Scenarios

This drive suits many industrial applications. It works well in packaging machinery. It is also great for material handling systems. The 2097-V32PR4 fits conveyor control setups. It performs well in labeling and filling machines. It is suitable for assembly line indexing. The drive operates in factory automation environments. It handles precise positioning tasks easily. Its Ethernet/IP connectivity enables seamless integration. It works with Rockwell Automation controllers. This drive is perfect for new builds or retrofits.

Technical Specifications

Input voltage ranges from 80 to 264V rms. Input frequency is 48 to 62 Hz. Main AC input current is 15.0 A. Continuous output current is 8.0 A rms. Peak output current reaches 24.0 A rms. Continuous power output is 1.70 kW. Power dissipation is 67 Watts. Torque value is 4.5 lb·in (0.5 N·m). Operating temperature is 32 to 104 F (0 to 40 C). Dimensions are 9.37 x 9.04 x 3.42 inches. Weight is 4.9 lbs (2.2 kg). Control power backup input is 20 to 26V DC. Nominal backup current is 500 mA. Max inrush backup current is 30 A.

Installation & Maintenance Guide

Mount the drive on a flat vertical surface. Ensure proper airflow around the unit. Use shielded cables for motor connections. Follow the manual for wiring diagrams. Check input voltage before powering up. Secure all connections tightly. Do not block the cooling vents. Keep the drive free of dust. Inspect terminals for signs of wear. Use a dry cloth for cleaning. Always disconnect power before maintenance. Test Safe Torque-Off function regularly. Update firmware as needed for performance.

Packing List

1 x Allen-Bradley 2097-V32PR4 Kinetix 300 Drive. 1 x Quick Start Guide. 1 x Safety Information Document. No additional cables or accessories included. The drive is packaged in a sturdy box. Shipping is via FedEx, UPS, or DHL. Ensure the package is inspected upon arrival. Report any damage to the carrier immediately.
