Flexem FR-D0808N Digital Mixed Input Module 8-Point NPN

Product Overview

The Flexem FR-D0808N is a reliable digital mixed input module. It combines input and output functions in a single unit. This module supports 8 bidirectional input channels. These channels are compatible with both NPN and PNP sensors. The rated voltage for inputs is 24VDC. The input range is 0 to 28.8V DC. The rated current per input is 7mA. The module also features 8 NPN output channels. The rated voltage for outputs is 24VDC. The output range is 19.2 to 28.8VDC. The rated current per output is 0.5A. Each group of outputs supports 0.5A. This design offers flexibility for many control tasks.

Application Scenarios

This module fits many industrial automation systems. Use it for discrete manufacturing lines. It works well for packaging machinery. It is also great for material handling systems. The bidirectional inputs accept various sensor types. This makes it easy to integrate with existing equipment. The NPN outputs can drive small relays and solenoids. Use the module in PLC and PAC systems. It is a good choice for machine builders. The compact size saves space in the control cabinet.

Technical Specifications

The FR-D0808N has 8 input channels. The input type is bidirectional. It works with NPN and PNP sensors. The rated input voltage is 24VDC. The input voltage range is 0 to 28.8V DC. The rated input current is 7mA. The module has 8 output channels. The output type is NPN. The rated output voltage is 24VDC. The output voltage range is 19.2 to 28.8VDC. The rated output current is 0.5A per point. The current per group is 0.5A. The dimensions are 111mm by 18mm by 76mm. The weight is 65 grams.

Installation & Maintenance Guide

Mount the module on a standard DIN rail. Ensure the power supply is off before wiring. Connect the 24VDC power to the correct terminals. Wire inputs according to your sensor type. Use NPN or PNP wiring methods. Wire outputs to your load devices. Check the polarity for all connections. Do not exceed the rated current limits. Keep the module in a clean, dry environment. Perform regular visual inspections. Tighten any loose connections. Replace the module if it shows signs of damage.

Packing List

The package includes one Flexem FR-D0808N module. It includes a quick start guide. No additional cables or connectors are included. Use standard wiring for installation. The module ships in protective packaging. Shipping is via Fedex, UPS, or DHL. Contact us for bulk orders.
