PLC Controller Allen-Bradley 1756-L82E ControlLogix 5580 Processor

Product Overview

The Allen-Bradley 1756-L82E is a powerful processor module. It belongs to the ControlLogix 5580 series. This module is a programmable automation controller. It handles complex industrial control tasks with ease. The device features 5 MB of user memory. It also ships with 2 GB of non-volatile storage. This storage is useful for data logging and recipes. The module supports full redundancy for critical applications. It offers built-in Ethernet I/P and a USB port. This processor is ideal for high-speed discrete and motion control.

Application Scenarios

This controller works well in many industries. Use it in automotive manufacturing lines. It excels in material handling systems. The module is great for packaging machinery. It also fits into oil and gas applications. The processor supports up to 128,000 digital I/O points. It can manage 4,000 analog I/O points. This makes it suitable for large-scale systems. The module handles 32 tasks and 1000 programs per task. It supports all event task triggers.

Technical Specifications

The 1756-L82E draws 5.0 mA at 1.2 Volts DC. It draws 1.20 mA at 5.1 Volts. The power dissipation is 6.2 Watts. Thermal dissipation is 21.2 BTU per hour. Isolation voltage is 50 Volts continuous. The enclosure type is open-style. The module supports optional communication adapters. These include ControlNet, DeviceNet, and SynchLink. It also supports third-party process networks. The module fully supports integrated motion control. This includes SERCOS and analog options.

Installation & Maintenance Guide

Install the module in a ControlLogix chassis. Ensure the chassis is properly grounded. Insert the module into an empty slot. Secure it with the locking mechanism. Connect the power supply to the chassis. Use the USB port for local programming. Use the Ethernet port for network connectivity. For maintenance, check the LED indicators. Keep the module free of dust and debris. Replace the module only when the system is off. Use proper ESD protection during handling.

Packing List

1 x Allen-Bradley 1756-L82E Processor Module. 1 x Installation Guide. 1 x Product Certificate. The module ships in an anti-static bag. It is packed in a sturdy cardboard box. Shipping is available via Fedex, UPS, or DHL. Contact us for bulk order discounts.
