129478-01 Bently Nevada High Voltage DC Power Input Module — New & In Stock

Introduction to the 129478-01

When industrial environments demand stable and robust power input, the 129478-01 from Bently Nevada stands ready. This Legacy High Voltage DC Power Input Module is part of the trusted 3500/15 series, engineered to convert high voltage DC into reliable power for your monitoring system. With an input voltage range of 88 to 140 Vdc, it handles demanding conditions while protecting downstream components.

Key Features and Technical Specs

• Input Voltage: 88 to 140 Vdc, ensuring compatibility with high voltage DC systems.
• Full Rack Current Draw: 2.5 A maximum, keeping power consumption predictable.
• Over-Voltage Protection: Fuse opens on the PIM to prevent damage from over-voltage events.
• Front Panel LED: Supply OK LED indicates when the power supply is operating properly.
• Dimensions: 120.7 mm x 25.4 mm x 114.3 mm (4.75 in x 1.0 in x 4.5 in), compact for rack mounting.
• Weight: 0.34 kg (0.75 lb), lightweight and easy to handle.
• Operating Temperature: -30 °C to +65 °C (-22 °F to +150 °F), suitable for harsh industrial settings.
• Storage Temperature: -40 °C to +85 °C (-40 °F to +185 °F), for safe long-term storage.
• Humidity: 95%, non-condensing, ensuring reliability in humid environments.

Real-World Applications

In industrial monitoring and control systems, the 129478-01 provides essential power input for Bently Nevada vibration monitoring racks. For example, in a turbine monitoring setup, this module ensures steady DC power to the rack, allowing continuous data collection. Similarly, in compressor stations, its wide temperature range supports outdoor installations. By using this module, engineers reduce the risk of power-related downtime.

Installation and Setup

Installing the 129478-01 is straightforward. It occupies two half-height slots on the left side of the rack, and both slots can hold a power supply simultaneously for redundancy. No minimum rack load is required, simplifying initial configuration. Always follow the manufacturer's manual for proper wiring and fuse selection.

Maintenance and Reliability

Routine inspection of the front panel Supply OK LED helps verify operational status. The module's robust design, with over-voltage protection via a fuse, minimizes maintenance needs. Operating within the -30 °C to +65 °C range ensures long service life. Regular checks of the fuse and connections are recommended per Bently Nevada guidelines.

Compatibility and Integration

The 129478-01 integrates seamlessly with Bently Nevada 3500/15 racks. It works with High Voltage DC Power Supplies to form a complete power input solution. For systems requiring redundancy, two power supplies can be installed in the rack simultaneously.

Troubleshooting and Common Issues

If the Supply OK LED is off, check the input voltage and fuse. An over-voltage condition will open the fuse on the PIM, so verify the source voltage stays within 88 to 140 Vdc. Under-voltage does not harm the supply or PIM, but the system may not operate correctly. Always consult the official Bently Nevada documentation for detailed diagnostics.

FAQ about 129478-01

Q: What is the input voltage range of the 129478-01?

A: The input voltage range is 88 to 140 Vdc.

Q: How much current does the 129478-01 draw from the rack?

A: The full rack current draw is 2.5 A maximum.

Q: What happens if an over-voltage occurs?

A: An over-voltage causes the fuse to open on the PIM, protecting downstream components.

Q: What are the operating temperature limits?

A: The operating temperature range is -30 °C to +65 °C (-22 °F to +150 °F).

Q: Can I use two power supplies for redundancy?

A: Yes, the rack has two half-height slots that can each hold a power supply, allowing redundant configuration.

Product Support and Availability

The 129478-01 is available from Petro Auto Tech. Please verify current lifecycle status and availability with Petro Auto Tech before ordering. In stock and ready to ship.
