170MCI02110 | Schneider 2m Shielded Communication Cable

Introduction to the Schneider 170MCI02110

When you need a reliable link between Momentum I/O bases, the 170MCI02110 from Schneider Electric delivers consistent performance. This round shielded cable is part of the Modicon Momentum series, engineered for industrial communication tasks. With a 2-meter length, it offers practical reach for various cabinet layouts, reducing installation strain and potential signal loss.

The cable operates at a voltage rating of 30 V and supports currents up to 1A, making it suitable for low-power control signals. Its proprietary MODBUS/Momentum I/O interface ensures seamless integration with compatible Momentum equipment, minimizing compatibility issues that can lead to downtime.

Key Features and Technical Specifications

• Connector A: 20-pin male – provides a secure, keyed connection.
• Connector B: 20-pin female – matches Momentum I/O base receptacles.
• Cable Length: 2 meters (typical) – offers flexibility in panel wiring.
• Voltage Rating: 30 V – safe for control-level signals.
• Current Rating: 1A – adequate for typical I/O communication.
• Operating Temperature: -10°C to +60°C – suits many industrial environments.
• Shielding: Yes (Foil + Drain) – reduces electromagnetic interference.
• Wire Gauge: 26 AWG – thin, flexible conductors.
• Conductor Material: Copper – ensures good conductivity.
• Jacket Material: PVC – durable and flexible.

The foil and drain shielding is a standout feature. It helps maintain signal integrity by minimizing EMI, which is critical in noisy industrial settings. This shielding reduces the risk of communication errors, leading to fewer production stoppages and lower troubleshooting costs.

Applications and Use Cases

The 170MCI02110 is designed for connecting Momentum I/O bases, making it essential in automation panels that use Modicon Momentum systems. Typical applications include material handling, packaging machinery, and process control where reliable I/O communication is vital.

For example, in a packaging line, this cable links sensors and actuators to the controller, ensuring timely responses. Its 2-meter length provides enough slack for routing through cable trays, simplifying installation and reducing strain on connectors.

Because it is RoHS compliant, the cable meets environmental regulations, which can be a factor for companies with green procurement policies. This compliance also avoids potential regulatory fines, contributing to long-term cost savings.

Installation and Setup

Installing the 170MCI02110 is straightforward. Align the 20-pin male connector with the female port on the Momentum I/O base and push firmly until it clicks into place. Ensure the cable is not bent sharply beyond its bend radius, as this could damage the shielding or conductors.

For best performance, route the cable away from high-voltage power lines to minimize electromagnetic interference. Use cable ties to secure it, but avoid over-tightening, which could crush the cable. Verify that the operating temperature stays within -10°C to +60°C to prevent insulation degradation.

Maintenance and Reliability

Regular inspection of the cable and connectors is recommended to maintain reliable operation. Check for signs of wear, such as cuts in the PVC jacket or bent pins. Loose connections can cause intermittent faults, so periodically reseat the connectors.

Because the cable is shielded, it is less susceptible to noise, which reduces the likelihood of communication errors. This reliability translates into fewer unplanned shutdowns, saving both time and money. The copper conductors and durable jacket contribute to a long service life, making this cable a cost-effective choice over time.

Compatibility and Integration

The 170MCI02110 is part of the Modicon Momentum series, so it is compatible with Momentum I/O bases that use a 20-pin interface. It supports the proprietary MODBUS/Momentum I/O protocol, ensuring seamless communication with compatible Schneider controllers.

Before ordering, verify that your Momentum base accepts a 20-pin connector. If you are unsure, consult the product manual or contact Petro Auto Tech for assistance. Proper compatibility avoids unnecessary returns and installation delays.

Frequently Asked Questions

Q: What is the cable length of the 170MCI02110?

A: The cable is typically 2 meters long, providing ample reach for connecting Momentum I/O bases.

Q: Does the 170MCI02110 support Modbus communication?

A: Yes, the interface type is proprietary MODBUS/Momentum I/O, designed for Momentum systems.

Q: Is the cable shielded?

A: Yes, it features foil and drain shielding to reduce electromagnetic interference.

Q: What is the operating temperature range?

A: The cable operates from -10°C to +60°C.

Q: Is the 170MCI02110 RoHS compliant?

A: Yes, it is RoHS compliant, meeting environmental standards.

Product Support and Availability

The 170MCI02110 is available through Petro Auto Tech, a trusted industrial automation parts supplier. We maintain stock to ensure quick delivery, helping you minimize downtime. Contact our team for current pricing and lead times.

For technical questions, refer to the official Schneider documentation or reach out to Petro Auto Tech for expert guidance.
