170XTS10000 | Schneider Modicon Momentum Front Labels Set of 10

Introduction: The 170XTS10000 Front Labels for Modicon Momentum

When you need to identify modules in a crowded control panel, the 170XTS10000 from Schneider Electric provides a straightforward solution. These front labels are part of the Modicon Momentum automation platform, designed specifically for Momentum modules. With a compact form factor and clear labeling, they help you maintain an organized and professional installation.

Each set includes 10 labels, giving you enough spares for multiple modules or future replacements. The labels are lightweight, weighing just 83 grams per package, and measure 0.29 inches in height, 4.92 inches in width, and 6.77 inches in length. This makes them easy to handle and apply without adding bulk to your existing setup.

Key Features and Technical Specifications

The 170XTS10000 is engineered for reliable performance in demanding industrial environments. Here are the key specifications you can expect:

• Manufacturer: Schneider Electric
• Product Type: Front Labels
• Product Line: Modicon Momentum
• Set Quantity: 10 labels per set
• Dimensions: 0.29 in (H) x 4.92 in (W) x 6.77 in (L)
• Weight: 83 g (2.9 oz)
• Cooling: Natural
• Max Ambient Temperature: 60 °C
• Min Ambient Temperature: 0 °C
• Max Operating Humidity: 95% (non-condensing)
• Max Storage Humidity: 95% (non-condensing)
• Max Altitude: 1000 m above sea level
• Standard Compliance: CE

These labels are designed to withstand temperatures from 0 °C to 60 °C, making them suitable for most indoor industrial settings. They can also handle humidity levels up to 95% non-condensing, both during operation and storage, which is ideal for humid environments. Additionally, they operate effectively at altitudes up to 1000 meters, covering most standard industrial locations.

Applications and Use Cases

The 170XTS10000 labels are ideal for any facility that uses Modicon Momentum modules. They are commonly used in manufacturing plants, process control systems, and building automation. By clearly labeling each module, you reduce the risk of operator error during maintenance or troubleshooting. For example, in a busy production line, these labels help technicians quickly identify which module controls a specific motor or sensor, saving valuable time.

Furthermore, because they are replacement parts, they are perfect for refreshing worn or damaged labels on existing Momentum modules. This simple upgrade can extend the life of your control panels and keep them looking professional.

Installation and Setup

Installing the 170XTS10000 front labels is a straightforward process. Simply remove the old label (if present) and apply the new one to the front face of the Momentum module. Ensure the surface is clean and dry before application. The labels are designed to fit the standard Momentum module dimensions, so no special tools are required.

For best results, align the label carefully before pressing it into place. Once applied, the label should lie flat and be clearly readable. If you are replacing labels on multiple modules, it is a good practice to do them one at a time to avoid mixing up labels.

Maintenance and Reliability

These labels are built to last, but like all components, they may require occasional inspection. Check periodically for peeling, fading, or damage, especially in harsh environments. If a label becomes illegible, replace it promptly to maintain clear identification. The natural cooling design means there are no moving parts to maintain, contributing to long-term reliability.

Because they are designed for the Modicon Momentum platform, you can trust that they will fit and perform as expected. Regular inspection and timely replacement of worn labels help ensure your control system remains safe and efficient.

Compatibility and Integration

The 170XTS10000 is specifically designed for Modicon Momentum modules. It is part of the Modicon Momentum automation platform, ensuring seamless compatibility with other Momentum components. Whether you are using processors, I/O bases, or connectors, these labels will fit the standard front panel dimensions.

This makes them a versatile choice for any Momentum-based control system. They are also a great addition to your spare parts inventory, so you always have replacements on hand when needed.

Frequently Asked Questions

Q: What is included in the 170XTS10000 package?

A: The package includes a set of 10 front labels, each measuring 0.29 x 4.92 x 6.77 inches, and weighing 83 grams in total.

Q: Can the 170XTS10000 labels be used outdoors?

A: The labels are rated for ambient temperatures from 0 °C to 60 °C and humidity up to 95% non-condensing. They are intended for indoor industrial use, not direct outdoor exposure.

Q: Are these labels CE certified?

A: Yes, the 170XTS10000 complies with CE standards, ensuring it meets required safety and performance criteria.

Q: How do I clean the labels?

A: Use a soft, dry cloth to gently wipe the surface. Avoid solvents or abrasive cleaners that could damage the label.

Q: Is the 170XTS10000 suitable for high-altitude installations?

A: Yes, it is designed to operate at altitudes up to 1000 meters above sea level.

Product Support and Availability

The 170XTS10000 is available from Petro Auto Tech, an industrial automation parts supplier. We stock genuine Schneider Electric components to ensure quality and reliability. Contact us for current availability and pricing.
