1756-BATM ControlLogix Battery Module Allen-Bradley

Product Overview

The Allen-Bradley 1756-BATM is a critical accessory for the ControlLogix platform. This externally mounted battery module ensures your controller memory stays intact during a power loss. It uses a reliable lithium chemistry with a nominal voltage of 3.6 Volts. The battery cell itself weighs only 10 grams. The complete assembly weighs 2.4 pounds or 1.1 kilograms. This unit offers a long shelf life of up to 10 years. It provides a steady output of 20mA at 3.6V DC. The input rating is 15mA at 5.1V DC. Maximum power dissipation is 4.5 Watts. This module is designed for industrial environments where data retention is vital.

Application Scenarios

This battery module works perfectly in factory automation systems. It is ideal for process control applications that require continuous uptime. Use it in assembly lines, packaging machines, and material handling systems. It supports critical data backup in oil and gas, water treatment, and power generation facilities. The 1756-BATM fits seamlessly into existing ControlLogix racks. It protects your program and configuration data from unexpected shutdowns. This makes it a standard part of any robust industrial control strategy.

Technical Specifications

Here are the key technical details for the 1756-BATM. The battery chemistry is Lithium. Nominal capacity is 1.7 Ah. Operating temperature ranges from 0° to 60° C. Storage temperature must be at or below 30° C. Relative humidity tolerance is 5 to 95 percent non-condensing. The maximum battery discharge current is 20mA. The module has a shock rating of 30G when panel mounted. It has a vibration rating of 2.0G at 10-500Hz. The cable length is 3.28 feet or 1 meter. Packaging dimensions are 2.65 by 1.34 by 2.44 inches. The UPC code is 10612598284761.

Installation & Maintenance Guide

Mount the 1756-BATM horizontally on a panel or DIN rail. Ensure the environment stays within the specified temperature range. Do not expose the battery to high heat or moisture. Check the module status indicator regularly. Replace the battery module before the end of its shelf life. Use only authorized Rockwell Automation replacements. Always follow standard safety procedures for lithium batteries. Proper installation ensures reliable memory backup for years.

Packing List

Your order includes one 1756-BATM battery module assembly. It comes with a pre-attached 1-meter cable. The package also contains a mounting bracket and instructions. All items are securely packed for shipping. We ship via FedEx, UPS, or DHL for fast delivery. This ensures your product arrives safely and on time.
