200151-40-03-02 | Bently Nevada 4.0m Accelerometer Standard Cable

What Makes the 200151-40-03-02 Essential for Vibration Monitoring?

When harsh industrial environments demand reliable signal transmission from accelerometers, the 200151-40-03-02 from Bently Nevada provides a robust solution. This accelerometer standard cable is engineered to connect sensors to monitoring systems, ensuring accurate data collection even under extreme temperatures. With a 4.0-meter length, blue armor, and a nylon coupling nut, it offers durability and flexibility for demanding installations.

Key Features & Technical Specs

• Cable length: 4.0 meters (model code -40).
• Armor option: Blue cable with armor (code 03).
• Coupling nut: Nylon coupling nut (code 02).
• Minimum bend radius: 63.5 mm (2.5 in).
• Operating temperature range: -20 ºC to +100 ºC (-4 ºF to +212 ºF).
• Construction: 4-conductor, 22 AWG with braided shield and drain wire (85% coverage, minimum), PVC outer jacket, nickel-plated coupling nuts.
• Seal: Connectors provide an IP67 seal to transducers and mating hardware, molded to the cable.
• DC4 electrical insulating compound in connectors provides additional protection against moisture during thermal shock.

Real-World Applications

In rotating machinery monitoring, the 200151-40-03-02 ensures stable signal transmission from accelerometers to data acquisition systems. Its armored construction withstands physical stress in oil and gas, power generation, and manufacturing plants. The IP67 seal protects against dust and water ingress, making it suitable for washdown environments. Additionally, the cable operates reliably across a wide temperature range, from -20 ºC to +100 ºC.

Installation & Setup

Install the 200151-40-03-02 by connecting the molded connectors to compatible Bently Nevada accelerometers and mating hardware. Ensure the cable is routed with a bend radius no smaller than 63.5 mm to prevent damage. For installations below -20 ºC, avoid flexing the cable to maintain integrity. The nylon coupling nut provides a secure, corrosion-resistant connection.

Maintenance & Reliability

Regularly inspect the cable jacket and connectors for wear or damage. The PVC outer jacket and braided shield offer long-term durability in industrial settings. The IP67 seal minimizes maintenance needs by preventing moisture ingress. For extended service life, avoid exposing the cable to temperatures outside the -20 ºC to +100 ºC range during operation.

Compatibility & Integration

The 200151-40-03-02 is designed for use with Bently Nevada accelerometers that accept standard interface cables with connectors on both ends. It integrates seamlessly into vibration monitoring systems, providing a reliable link between sensors and monitoring hardware. The 4-conductor, 22 AWG construction supports accurate signal transmission for predictive maintenance applications.

FAQs about the 200151-40-03-02

Q: What is the cable length of the 200151-40-03-02?

A: The cable length is 4.0 meters, as indicated by the -40 code in the model number.

Q: Does the cable have armor protection?

A: Yes, the 200151-40-03-02 features a blue cable with armor (armor option 03).

Q: What type of coupling nut is used?

A: It uses a nylon coupling nut (coupling nut option 02).

Q: What is the operating temperature range?

A: The operating temperature range is -20 ºC to +100 ºC (-4 ºF to +212 ºF).

Q: Is the connector sealed against moisture?

A: Yes, connectors provide an IP67 seal and are molded to the cable, with DC4 insulating compound for added moisture protection.

Product Support & Availability

The 200151-40-03-02 is in stock and ready to ship from Petro Auto Tech. Contact our team for pricing and availability. We are your trusted source for Bently Nevada automation parts.
