200157-07-05 | Bently Nevada 10.2 mV/(m/s²) Enveloping Trendmaster Pro Accelerometer

Introduction: The Evolution of Bearing Protection

In the early days of industrial monitoring, engineers relied on manual vibration checks to catch bearing faults before catastrophic failure. As rotating machinery grew more complex, the need for precise, continuous acceleration sensing became clear. The 200157-07-05 from Bently Nevada represents a leap forward in enveloping accelerometer technology, designed specifically for roller element bearing analysis and cavitation detection. With a sensitivity of 10.2 mV/(m/s²) at 80 Hz and a measurement range of ±245 m/s², this sensor captures the subtle high-frequency signatures that precede bearing damage.

Key Features & Technical Specs of the 200157-07-05

• Sensitivity: 10.2 mV/(m/s²) ±12% at 80 Hz ensures accurate vibration measurement.
• Frequency Range: 10 to 10,000 Hz (600 to 600,000 cpm) covers both low-speed and high-speed machinery.
• Measurement Range: ±245 m/s² (±25 g) handles normal to severe vibration levels.
• Mounted Resonant Frequency: >20 kHz (>1200 kcpm) provides wide bandwidth for enveloping analysis.
• Excitation Voltage: 4.7 to 5.5 Vdc, compatible with standard industrial power supplies.
• Output Bias Voltage: +2.5 ± 0.23 Vdc for consistent signal baseline.
• Temperature Range: -40 °C to +105 °C (-40 °F to +221 °F) suits harsh environments.
• Sealing: Hermetic at 5×10⁻⁸ atm·cc/s maximum prevents moisture ingress.
• Weight: 58 g (2.0 oz) typical, compact for tight installations.

Applications & Use Cases for the 200157-07-05

This accelerometer excels in monitoring roller element bearings in pumps, motors, compressors, and turbines. The enveloping channel type (-06) extracts bearing defect frequencies from background noise, enabling early fault detection. In paper mills, for example, the 200157-07-05 helps prevent unplanned downtime by identifying spalling or brinelling before failure. It also detects cavitation effects in centrifugal pumps, protecting impellers and casings from erosion.

Installation & Setup Guidance

Mount the 200157-07-05 using the 3/8-24 female thread onto a flat, clean surface. Apply a mounting torque of 2.7 to 6.8 N·m (2 to 5 ft·lbf) using the provided 3/8-24 to 3/8 NPT stud option (07). Ensure the cable is routed away from high-temperature sources and moving parts. Allow 24 hours cure time for any applied thread-locking compound. The accelerometer settling time is ≤300 ms within 5% of bias voltage after power-up.

Maintenance & Reliability

Routine inspection of the accelerometer and its cable is recommended every six months. Check for physical damage, corrosion, or loose mounting. The 316L stainless steel housing and hermetic sealing protect against moisture and corrosive atmospheres. With proper care, the 200157-07-05 delivers long-term reliability in continuous monitoring applications.

Compatibility & Integration

The 200157-07-05 is designed for use with Bently Nevada ProTIM modules that support standard acceleration-to-velocity with acceleration enveloping. It provides a SIG+ positive signal relative to SIG- for easy integration into existing monitoring systems. Multiple approvals (CSA, ATEX, IECEx) allow deployment in hazardous areas worldwide.

FAQ about 200157-07-05

Q: What is the sensitivity of the 200157-07-05?

A: The sensitivity is 10.2 mV/(m/s²) ±12% at 80 Hz.

Q: What is the frequency range of this accelerometer?

A: The frequency range is 10 to 10,000 Hz (600 to 600,000 cpm).

Q: What mounting thread does the 200157-07-05 use?

A: It uses a 3/8-24 female thread with a mounting torque of 2.7 to 6.8 N·m (2 to 5 ft·lbf).

Q: Is the 200157-07-05 suitable for hazardous areas?

A: Yes, it has multiple approvals including CSA, ATEX, and IECEx.

Q: What is the output bias voltage?

A: The output bias voltage is +2.5 ± 0.23 Vdc.
