2094-BC01-M01-S | Allen-Bradley Kinetix 6000 Integrated Axis Module - Petro Auto Tech

Product Overview

The 2094-BC01-M01-S is a 400 Volt class Integrated Axis Module from the Kinetix 6000 Motion control system by Allen-Bradley. This multi-axis servo drive integrates a converter and inverter section to deliver precise motion control for demanding industrial applications. It includes Safe Torque Off (STO) functionality for enhanced safety.

Technical Specifications Analysis

The 2094-BC01-M01-S operates on a 3-phase AC input voltage range of 324 - 528Vrms, with nominal voltages of 360/480 VAC. It delivers a continuous power output to bus of 6 kW and a continuous output current to bus of 9 Amperes. Peak power output reaches 12 kW. The module supports DC input voltage from 458 to 747 VDC for common-bus configurations. It features bus overvoltage protection at 425V DC and undervoltage at 275V DC. Efficiency is rated at 97%. The unit weighs 11.1 pounds and mounts on a power rail with a minimum enclosure depth of 198 mm and installation clearance of 50.8 mm.

Application Scenarios & Usage Methods

This drive excels in multi-axis packaging machines, converting lines, and assembly systems where synchronized motion is critical. Use the 2094-BC01-M01-S as a common-bus follower to share DC bus power across multiple axes, reducing energy consumption. The integrated STO function allows safe maintenance without removing power, improving uptime.

Installation Guide & Packing List

Mount the module on a power rail in an enclosure with at least 198 mm depth. Maintain 50.8 mm clearance around the unit for airflow. Connect 3-phase AC input within 324-528Vrms. For common-bus operation, supply 458-747 VDC. The package includes the 2094-BC01-M01-S Integrated Axis Module and mounting hardware.

Purchasing Advice

When selecting the 2094-BC01-M01-S, verify your system voltage matches the 360/480 VAC nominal input. For multi-axis systems, confirm DC bus compatibility with other Kinetix 6000 modules. Petro Auto Tech offers this module with fast delivery and expert support to ensure correct integration.

Repair & Maintenance Tips

Periodically inspect the power rail connections and ensure the enclosure stays within specified clearance. Keep the module clean and dry. Check bus voltage levels to stay within 458-747 VDC. Replace the unit if STO fault indicators activate.

Frequently Asked Questions (FAQs)

Q: What is the continuous power output of the 2094-BC01-M01-S?

A: The continuous power output to bus is 6 kW.

Q: Does the 2094-BC01-M01-S support Safe Torque Off?

A: Yes, it includes integrated Safe Torque Off (STO) functionality.

Q: What is the AC input voltage range?

A: The AC input voltage range is 324 - 528Vrms, 3-Phase.

Q: What is the weight of the module?

A: It weighs 11.1 pounds.

Q: Can this module be used as a common-bus follower?

A: Yes, it supports a DC input voltage of 458-747 VDC for common-bus operation.
