330101-00-11-10-02-CN | Bently Nevada 8 mm Probe, 1.0 m Cable

Introduction: The Evolution of Precision Monitoring

In the world of industrial machinery, the ability to detect subtle vibrations before they escalate into catastrophic failures has transformed maintenance strategies. The 330101-00-11-10-02-CN from Bently Nevada represents a leap forward in this evolution. As part of the 3300 XL series, this 8 mm probe with a 3/8-24 UNF thread and a 1.0 metre cable is engineered for robust, accurate vibration sensing in demanding environments. Whether you are upgrading an aging system or building a new monitoring network, this probe offers the reliability that modern plants require.

Key Features & Technical Specs of the 330101-00-11-10-02-CN

• Probe Type: 3300 XL 8 mm Probe with 3/8-24 UNF thread, without armor.
• Total Length: 1.0 metre (3.3 feet) including cable.
• Connector: Miniature coaxial ClickLoc connector with standard cable.
• Linear Range: 2 mm (80 mils) from approximately 0.25 mm to 2.3 mm from target.
• Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±5% for 1 or 5 meter systems over 0°C to +45°C.
• Probe Tip Material: Polyphenylene sulfide (PPS) for durability.
• Probe Case Material: AISI 303 or 304 stainless steel.
• Operating Temperature: Standard probe from -52°C to +177°C.
• Nominal Probe DC Resistance: 7.59 ± 0.50 Ω for 1.0 m length.
• Weight: 323 g/m (11.4 oz/m).

One standout spec is the patented TipLoc and CableLoc designs, which provide 330 N (75 lbf) pull strength for secure cable attachment. This reduces downtime caused by cable failures in high-vibration settings.

Real-World Applications for the 330101-00-11-10-02-CN

This probe excels in rotating machinery monitoring, such as turbines, compressors, and pumps. Its 8 mm diameter offers a thicker PPS encapsulation, making it more rugged than smaller probes. In oil and gas facilities, the optional FluidLoc cable prevents liquid leaks through the cable interior. The linear range of 2 mm (80 mils) ensures accurate vibration readings from 0.25 mm to 2.3 mm, ideal for early fault detection.

Installation Guide for the 3300 XL Probe

Mount the probe using the 3/8-24 UNF thread into a suitable mounting block. For field wiring, use 0.2 to 1.5 mm² (16 to 24 AWG) three-conductor shielded triad cable. The maximum cable length between the Proximitor Sensor and monitor is 305 meters (1,000 feet). Set the recommended gap for radial vibration to -9 Vdc, approximately 1.27 mm (50 mils). Ensure the probe tip is clean and free from debris before installation.

Maintenance & Reliability Tips

Regularly inspect the probe cable and connector for wear, especially in high-temperature environments. The probe operates reliably from -52°C to +177°C, but exposure below -34°C may cause premature pressure seal failure. The Viton O-ring seals differential pressure, but probes are not pressure tested before shipment. For extended temperature ranges, the probe tip can withstand up to +218°C. Periodic verification of the Incremental Scale Factor ensures measurement accuracy.

Compatibility & Integration

The 330101-00-11-10-02-CN integrates seamlessly with Bently Nevada 3300 XL Proximitor Sensors and monitoring systems. The ClickLoc connector simplifies cable attachment. Use with standard 5 or 1 meter systems for optimal performance. For extended temperature range systems, the ISF remains within ±6.5%.

FAQ about the 330101-00-11-10-02-CN

What is the linear range of this probe?

The linear range is 2 mm (80 mils), starting at approximately 0.25 mm from the target and extending to 2.3 mm.

What is the recommended gap setting for radial vibration?

Set the gap to -9 Vdc, which corresponds to approximately 1.27 mm (50 mils).

What is the operating temperature range for the standard probe?

The standard probe operates from -52°C to +177°C (-62°F to +350°F).

What type of connector does the 330101-00-11-10-02-CN use?

It uses a miniature coaxial ClickLoc connector with standard cable.

What is the weight of the probe cable?

The cable weighs 323 g/m (11.4 oz per meter).

Product Support & Availability

The Bently Nevada 330101-00-11-10-02-CN is in stock and ready to ship from Petro Auto Tech. Contact our team for pricing and lead times. We provide expert support to ensure you select the right probe for your application.
