21000-16-10-00-120-03-02 | Bently Nevada 8 mm Probe Housing Assembly

Cost-Effective Vibration Monitoring with the 21000-16-10-00-120-03-02

When unplanned downtime drives up operational costs, the 21000-16-10-00-120-03-02 from Bently Nevada delivers a reliable solution. This proximity probe housing assembly is engineered for continuous vibration monitoring in rotating machinery. By catching early signs of bearing wear or imbalance, it helps you avoid expensive repairs and production losses. The 21000-16-10-00-120-03-02 is a smart investment for long-term asset protection.

Key Features & Technical Specs of the 21000-16-10-00-120-03-02

• Probe Option: 3300 XL 8 mm probe with connector for precise measurement.
• Cable Length: 1.0 m (39 in) cable reduces installation complexity and cost.
• Material: Aluminum body with 304 stainless steel sleeve ensures durability in harsh environments.
• Fittings: Includes one 3/4-14 NPT plug, one 3/4-14 to 1/2-14 NPT reducer, and a cable seal grip with grommets for multiple cable sizes (1/8 to 3/8 inches).
• Mounting Thread: 3/4-14 NPT for secure installation.
• Weight: 1.1 kg (2.4 lb) typical, without fittings, for easy handling.
• Probe Penetration: 12 in for flexible mounting options.
• Approvals: CSA certified as explosion proof for hazardous areas; CSA Type 4 enclosure; compliant with API 670 Standard.

The 8 mm probe size is a distinctive spec that allows for high-resolution measurements in tight spaces, directly reducing retrofit costs.

Real-World Applications for the 21000-16-10-00-120-03-02

In petrochemical plants, the 21000-16-10-00-120-03-02 monitors critical pumps and compressors. Its explosion-proof rating ensures safe operation in hazardous zones. Additionally, power generation facilities use this assembly to track turbine shaft vibrations, preventing catastrophic failures. The API 670 compliance makes it a standard choice for refineries seeking reliable, cost-efficient monitoring.

Installation & Setup Guide

Mount the 21000-16-10-00-120-03-02 using the 3/4-14 NPT thread for a secure fit. First, select the appropriate cable seal grip grommet for your cable size (1/8 to 3/8 inches). Then, attach the 3300 XL 8 mm probe with the 1.0 m cable. Finally, connect the conduit fittings as needed. Always follow the manufacturer's manual for proper torque and alignment to ensure accurate readings.

Maintenance & Reliability for Cost Savings

Regular inspection of the 21000-16-10-00-120-03-02 extends its service life. Check the O-rings and thread seal periodically for wear. The aluminum and stainless steel construction resists corrosion, reducing replacement frequency. This reliability translates into lower total cost of ownership over time.

FAQs about the 21000-16-10-00-120-03-02

Q: What is the probe cable length for the 21000-16-10-00-120-03-02?

A: The cable length is 1.0 m (39 in), as specified by suffix code 10.

Q: Is the 21000-16-10-00-120-03-02 suitable for hazardous areas?

A: Yes, it is CSA certified as explosion proof for hazardous areas and is CSA Type 4 rated.

Q: What mounting thread does the 21000-16-10-00-120-03-02 use?

A: It uses a 3/4-14 NPT thread, as indicated by suffix code -02.

Q: What probe option is included with the 21000-16-10-00-120-03-02?

A: It includes a 3300 XL 8 mm probe with connector, per suffix code 16.

Q: What is the typical weight of the 21000-16-10-00-120-03-02?

A: The typical weight is 1.1 kg (2.4 lb) without fittings.

Product Support & Availability

The 21000-16-10-00-120-03-02 is in stock and ready to ship. Contact Petro Auto Tech for pricing and lead times.
