24701-16-05-25-059-04-02 | Bently Nevada 8mm Probe Housing Assembly

Introduction to the Bently Nevada 24701-16-05-25-059-04-02

When you need a rugged and precise housing for your proximity probe, the 24701-16-05-25-059-04-02 from Bently Nevada delivers. This assembly is part of the trusted 24701 series, engineered for industrial vibration monitoring. It combines a 3300 XL 8mm probe with a robust stainless steel body, ensuring dependable performance in demanding environments.

The assembly includes a dome cover, threaded ports for conduit connections, a probe sleeve, O-rings, a reverse mount proximity probe, a thread seal, and optional conduit fittings. With a 12-month factory warranty and new original factory packing, you can rely on its quality.

Key Features and Technical Specifications

Understanding the exact specifications helps you verify compatibility. Here are the critical details for the 24701-16-05-25-059-04-02:

• Probe Option: 3300 XL 8mm probe with connector
• Probe Cable Length: 20 inches (0.5 meters)
• Standoff Adapter: 2.5 inches
• Probe Penetration: 5.9 inches
• Fittings Option: One 3/4-14 NPT plug only
• Mounting Thread: 3/4-14 NPT
• Body Material: 303 stainless steel with 304 stainless steel sleeve
• Weight: 1.8 kg (4.1 lb) typical, without fittings

One distinctive feature is the 8mm probe size, which is a common choice for rotating machinery. This size balances sensitivity and durability, making it suitable for a wide range of vibration monitoring applications.

Applications and Use Cases

The 24701-16-05-25-059-04-02 is ideal for turbomachinery, pumps, compressors, and other rotating equipment where shaft vibration must be monitored. Its stainless steel construction withstands harsh industrial environments. Furthermore, the 0.5 m cable length is convenient for installations where the probe is close to the monitoring system. For example, in a compressor train, this housing assembly helps maintain accurate vibration readings, contributing to predictive maintenance strategies.

Installation and Setup

Proper installation ensures accurate measurements. The mounting thread is 3/4-14 NPT, which fits standard conduit connections. The standoff adapter of 2.5 inches positions the probe correctly. When installing, verify that the probe penetration of 5.9 inches matches your machine's clearance. Also, ensure the cable length of 0.5 meters reaches your junction box without strain. Always follow the manufacturer's guidelines for torque and gap settings.

Maintenance and Reliability

Regular inspection of the housing assembly is recommended to maintain performance. Check for any signs of wear on the O-rings and thread seal. Periodically verify that the probe is securely mounted and that the cable is not damaged. Because the body is stainless steel, it resists corrosion, extending service life. Consequently, this reduces downtime and replacement costs, offering long-term value.

Compatibility and Integration

This housing assembly is designed to work with Bently Nevada monitoring systems that accept 3300 XL 8mm probes. It is compatible with standard 3/4-14 NPT conduit fittings. For integration, you will need a compatible proximitor and extension cable (not included). Always confirm that your system supports the 8mm probe format.

Troubleshooting and Common Issues

If you encounter erratic readings, check the probe gap and cable connections. Loose fittings can cause signal noise. Ensure that the standoff adapter is correctly installed to maintain the proper gap. Also, verify that the probe tip is clean and free of debris. For persistent issues, consult the Bently Nevada documentation or contact Petro Auto Tech for assistance.

Frequently Asked Questions

Q: What is the probe size for the 24701-16-05-25-059-04-02?

A: The probe option is a 3300 XL 8mm probe, which is a standard size for many vibration monitoring applications.

Q: What is the cable length of this assembly?

A: The probe cable length is 20 inches (0.5 meters), which is suitable for close-range installations.

Q: What mounting thread does the housing use?

A: The mounting thread option is 3/4-14 NPT, which is a common industrial standard.

Q: Is the body made of stainless steel?

A: Yes, the body is 303 stainless steel with a 304 stainless steel sleeve, providing excellent corrosion resistance.

Product Support and Availability

The 24701-16-05-25-059-04-02 is available from Petro Auto Tech, an industrial automation parts supplier. It comes with a 12-month factory warranty and is shipped in new, original factory packing. Contact Petro Auto Tech for current availability and ordering information.
