24701-16-10-00-083-03-02 | Bently Nevada 8mm Probe Housing Assembly

Introduction to the Bently Nevada 24701-16-10-00-083-03-02

When your rotating machinery demands precise vibration monitoring, the 24701-16-10-00-083-03-02 from Bently Nevada delivers the rugged protection your proximity probe needs. This housing assembly is part of the trusted 24701 series, engineered to safeguard a 3300 XL 8mm probe in demanding industrial environments. With a stainless steel body and a 1.0 m probe cable, this unit is ready for installation in your critical asset monitoring system.

As a new, factory-packed component, the 24701-16-10-00-083-03-02 ensures you receive original Bently Nevada quality. The 12-month factory warranty provides added confidence for your maintenance planning. Whether you are upgrading an existing system or building a new one, this housing assembly is a dependable choice.

Key Features and Technical Specifications

The 24701-16-10-00-083-03-02 is built with precision and durability in mind. Below are the core specifications that define its performance:

• Probe Option: 3300 XL 8mm probe with connector
• Probe Cable Length: 39 in (1.0 m)
• Probe Penetration: 8.3 in
• Mounting Thread: 3/4-14 NPT
• Fittings: Includes 3/4-14 NPT plug, reducer, and cable seal grip
• Material: 303 stainless steel body with 304 stainless steel sleeve
• Weight: 1.8 kg (4.1 lb) typical, without fittings

One distinctive feature is the 8.3-inch probe penetration, which allows the sensor to reach deep into the measurement point. This is particularly useful in applications where the probe must be positioned close to the shaft without interference. The 3/4-14 NPT mounting thread ensures a secure, leak-proof installation in standard conduit openings.

Applications and Use Cases

In industrial settings, the 24701-16-10-00-083-03-02 is commonly used for vibration monitoring of turbines, compressors, pumps, and motors. Its robust construction protects the probe from harsh environmental conditions, ensuring accurate readings over time. For example, in a petrochemical plant, this housing assembly can be installed on a critical pump to continuously monitor shaft vibration, helping to detect early signs of imbalance or misalignment.

Additionally, the housing assembly is suitable for applications where space is limited, thanks to its compact design and optional standoff adapter. The absence of a standoff adapter in this configuration simplifies installation in tight areas, while still providing full protection to the probe.

Installation and Setup

Installing the 24701-16-10-00-083-03-02 is straightforward, but it requires attention to detail. Begin by verifying that the mounting thread (3/4-14 NPT) matches your conduit opening. Then, feed the probe cable through the housing and connect it to the probe. Ensure the cable seal grip is tightened to prevent moisture ingress. The included fittings—a 3/4-14 NPT plug, a reducer, and a cable seal grip—accommodate cable sizes from 1/8 to 3/8 inches, providing flexibility for various wiring setups.

For optimal performance, position the probe so that the penetration depth (8.3 in) aligns with your measurement target. Refer to the Bently Nevada installation manual for detailed torque specifications and clearance requirements. If you need assistance, Petro Auto Tech can provide guidance based on your specific application.

Maintenance and Reliability

Regular inspection of the 24701-16-10-00-083-03-02 ensures long-term reliability. Periodically check the housing for signs of corrosion or damage, especially in corrosive environments. Verify that all fittings remain tight and that the cable seal grip is intact. The stainless steel construction offers excellent resistance to rust, but routine checks are still recommended.

Because this housing assembly is designed for continuous operation, minimal maintenance is required. However, if you notice any degradation in signal quality, inspect the probe and cable for wear. Replacing worn components promptly prevents unplanned downtime and extends the life of your monitoring system.

Compatibility and Integration

The 24701-16-10-00-083-03-02 is designed to work seamlessly with Bently Nevada 3300 XL 8mm proximity probes. It is also compatible with standard Bently Nevada monitoring systems that accept 8mm probes. The 1.0 m cable length is ideal for installations where the monitor is located close to the machine. For longer distances, you may need to use an extension cable, but always consult the manufacturer's guidelines to ensure signal integrity.

This housing assembly does not include a standoff adapter, which means it is intended for direct mounting. If your application requires a standoff, you may need to order a different configuration. Contact Petro Auto Tech to verify compatibility with your existing system.

Troubleshooting and Common Issues

One common issue with proximity probe housings is improper cable sealing, which can lead to moisture ingress and signal degradation. The included cable seal grip mitigates this risk, but it must be installed correctly. If you experience intermittent readings, check the cable connections and ensure the grip is snug.

Another potential issue is incorrect probe penetration, which can result in inaccurate measurements. Verify that the probe is positioned at the correct distance from the shaft, as specified in your system's calibration. If problems persist, consult the Bently Nevada documentation or contact Petro Auto Tech for technical support.

FAQ about the 24701-16-10-00-083-03-02

Q: What is the probe cable length of this housing assembly?

A: The probe cable length is 39 inches (1.0 meter), as specified by the option code 10.

Q: What mounting thread does the 24701-16-10-00-083-03-02 use?

A: It uses a 3/4-14 NPT mounting thread, which is standard for many industrial conduit connections.

Q: Does this housing assembly include a standoff adapter?

A: No, this configuration has no standoff adapter (option 00). It is designed for direct mounting.

Q: What is the probe penetration depth?

A: The probe penetration is 8.3 inches, allowing deep sensor placement for accurate measurements.

Q: What materials are used in the construction?

A: The body is made of 303 stainless steel, and the sleeve is 304 stainless steel, providing excellent corrosion resistance.

Product Support and Availability

The 24701-16-10-00-083-03-02 is available through Petro Auto Tech, your trusted industrial automation parts supplier. We offer new, original factory-packed units with a 12-month warranty. Contact us to check current availability and lead times. Our team is ready to assist you with any technical questions.
