31000-16-10-15-041-03-02 | Bently Nevada 8 mm Probe Housing

Introduction to the 31000-16-10-15-041-03-02

When machine vibration threatens uptime, the 31000-16-10-15-041-03-02 from Bently Nevada provides a robust housing solution for 3300 XL 8 mm proximity probes. This industrial-grade enclosure protects sensitive sensors in harsh environments, ensuring accurate data for predictive maintenance. By choosing this housing, you reduce the risk of probe damage and costly unplanned downtime.

Key Features & Technical Specifications

• Designed for 3300 XL 8 mm probe with connector option 16.
• Probe cable length of 1.0 m (39 in) for flexible installation.
• Standoff adapter with minimum length 1.5 in (38 mm) for precise positioning.
• Probe penetration of 4.1 in to accommodate various mounting depths.
• Mounting thread 3/4-14 NPT, required when using the standoff adapter.
• Housing material: glass-reinforced PPS thermoplastic with conductive fibers.
• Sleeve and retaining chain made of AISI 304 stainless steel; outer sleeve and screws of AISI 303 stainless steel.
• Neoprene O-ring for reliable sealing.
• Temperature rating from -51°C to +105°C (-60°F to +221°F).
• Weight of 1.2 kg (2.6 lb) typical.

One standout feature is the impact strength: certified by BASEEFA to withstand two 4 Joule impacts at extreme temperatures, and CSA-verified for a 7 Joule impact at room temperature. This durability translates into fewer replacements and lower lifecycle costs.

Applications & Use Cases

This housing is ideal for rotating machinery monitoring in industries like power generation, oil and gas, and manufacturing. For example, in a steam turbine application, the 31000-16-10-15-041-03-02 reliably holds the proximity probe, enabling continuous vibration measurement. Consequently, maintenance teams can detect issues early and avoid catastrophic failures. Moreover, its IP66 rating makes it suitable for outdoor or washdown environments, reducing the need for frequent maintenance.

Installation & Setup

Proper installation is key to maximizing performance. First, ensure the mounting thread (3/4-14 NPT) matches your application. Then, use the recommended torque of 29.4 N·m (260 in·lb) for the retaining nut to secure the housing. After that, connect the probe cable and verify the penetration depth is correct. Finally, test the assembly to confirm the probe is positioned accurately for reliable readings.

Maintenance & Reliability

Regular inspection of the housing and O-ring helps maintain its protective seal. Because the housing is built from corrosion-resistant stainless steel and impact-resistant PPS, it withstands harsh conditions, thereby extending service life and reducing replacement costs. Periodically check the cable and fittings for wear, and replace any damaged components promptly to avoid downtime.

Compatibility & Integration

The 31000-16-10-15-041-03-02 is specifically designed for Bently Nevada 3300 XL 8 mm proximity probes. It integrates seamlessly with Bently Nevada monitoring systems, ensuring accurate signal transmission. For other system compatibility, consult the official documentation or contact Petro Auto Tech for guidance.

Troubleshooting & Common Issues

If you experience signal loss, first verify the probe cable connection and the integrity of the fittings. A loose retaining nut can cause vibration, so check torque periodically. Also, inspect the O-ring for damage that could allow moisture ingress. By addressing these common issues, you maintain reliable operation and avoid costly repairs.

FAQs

Q: What is the temperature range for the 31000-16-10-15-041-03-02?

A: The housing operates from -51°C to +105°C (-60°F to +221°F), making it suitable for extreme environments.

Q: What mounting thread does this housing use?

A: It uses a 3/4-14 NPT thread, which is required when ordering the standoff adapter.

Q: Is the housing impact-resistant?

A: Yes, it is certified to withstand 4 Joule impacts at -39°C and 115°C, and 7 Joule at room temperature.

Q: What probe is compatible with this housing?

A: It is designed for the 3300 XL 8 mm probe with connector option 16.

Q: What is the weight of the housing?

A: The typical weight is 1.2 kg (2.6 lb).

Product Support & Availability

The 31000-16-10-15-041-03-02 is available through Petro Auto Tech. Contact our team to check stock and lead times. We are ready to assist with your order and provide technical support.
