3500/94M-05-00-00 | Bently Nevada VGA Display Module - Petro Auto Tech

Product Overview

The 3500/94M-05-00-00 is a VGA Display Module from Bently Nevada, designed for industrial monitoring systems. This module provides a high-visibility 15-inch display in a 19-inch rack mount format, enabling operators to view machine status, data, and values in real time. It integrates seamlessly with the 3500 series monitoring system, offering reliable performance in demanding environments.

Technical Specifications Analysis

The 3500/94M-05-00-00 operates with a power consumption of 4.6 watts max. It includes a high-speed network connection for monitor status and data, an RS232 port for touch controller data, and a VGA port for analog red, green, blue, and sync signals. The front port provides 24 Vdc power out, VGA signal out, and touch commands in. Environmental limits include an operating temperature range of -20°C to 65°C (-22°F to 149°F) and storage temperature from -40°C to 85°C (-40°F to 185°F), with humidity tolerance up to 95% non-condensing. The module complies with EMC standards EN 61000-6-2 and EN 61000-6-4, electrical safety standards CSA C22.2 61010-1 and UL EN 61010-1, and RoHS Directive 2011/65/EU.

Application Scenarios & Usage Methods

This VGA display module is ideal for continuous monitoring of rotating machinery in power plants, oil refineries, and manufacturing facilities. Operators use the 15-inch screen to view vibration data, temperature trends, and alarm status from the 3500 monitoring system. The RS232 port connects to a touch controller for intuitive navigation, while the VGA port outputs clear analog signals. In a typical setup, the module mounts in a 19-inch rack and connects to a 3500/22 Transient Data Interface (TDI) module for data acquisition.

Installation Guide & Packing List

Install the monitor module in one full-height front slot and the I/O module in one full-height rear slot of the 3500 rack. Ensure the KVM extender, if used, is mounted on the shelf top with 12 Vdc and 5 Vdc power input. The package includes the 3500/94M VGA Display Module (I/O module and monitor module), a 15-inch Advantech display (FPM-8151H), and necessary cables. No additional accessories are included unless specified.

Purchasing Advice

When purchasing the 3500/94M-05-00-00, verify compatibility with your existing 3500 rack and firmware versions (e.g., 3500/94M Firmware 4.06 Rev. C). This module is suited for applications requiring a rugged display in non-hazardous areas. Petro Auto Tech offers genuine Bently Nevada modules with reliable sourcing. Check the display size and mounting option (05 = 15" display, 19" rack mount) to match your enclosure.

Repair & Maintenance Tips

Regularly inspect the module for dust accumulation on the display and vents. Clean with a soft, dry cloth. Ensure the operating temperature stays within -20°C to 65°C and humidity below 95% non-condensing. Verify the OK LED indicates proper operation and the TX/RX LED shows communication. Store the module in a dry environment between -40°C and 85°C when not in use. Avoid exposure to corrosive gases or liquids.

Frequently Asked Questions (FAQs)

Q: What is the power consumption of the 3500/94M-05-00-00?

A: The module consumes 4.6 watts max.

Q: What is the operating temperature range for this display module?

A: It operates from -20°C to 65°C (-22°F to 149°F).

Q: Does the 3500/94M-05-00-00 require a specific interface module?

A: Yes, it requires a 3500/22 Transient Data Interface (TDI) module.

Q: What display size and mounting are included with this model?

A: It includes a 15-inch display with 19-inch rack mount.

Q: What certifications does the module hold?

A: It complies with FCC Part 15, EMC standards EN 61000-6-2 and EN 61000-6-4, and electrical safety standards CSA C22.2 61010-1 and UL EN 61010-1.
