Product Overview

The 3500/94M-06-00-01 is a Bently Nevada VGA Display Module designed for industrial monitoring systems. This module provides real-time display of machinery status, data, and vibration values from the 3500 series rack. With a 15-inch panel mount display and robust environmental tolerance, it ensures reliable operation in demanding automation environments.

Technical Specifications Analysis

The 3500/94M-06-00-01 operates with a power consumption of 4.6 watts max. It includes a high-speed network interface for monitoring status and data, an RS232 port for touch controller data, and a VGA port for analog red, green, blue, and sync signals. The module features an OK LED for proper operation indication and a TX/RX LED for communication status. Environmental limits include an operating temperature range of -20°C to 65°C (-22°F to 149°F) and storage temperature from -40°C to 85°C (-40°F to 185°F), with humidity tolerance up to 95% non-condensing. The display size and mounting option is 06=15" display, panel mount, with installation hardware included. Agency approval is CSA/NRTL/C (Class I, Division 2). Weight is 1.07 kg.

Application Scenarios & Usage Methods

This VGA display module is ideal for continuous machinery health monitoring in power generation plants, oil and gas facilities, and manufacturing lines. Operators use it to view real-time vibration data and system status from Bently Nevada 3500 series racks. The RS232 port allows touch screen calibration and data input, while the VGA output connects to external displays for larger viewing. The module supports Class I, Division 2 hazardous area installations, making it suitable for environments with flammable gases or vapors.

Installation Guide & Packing List

Install the 3500/94M-06-00-01 in a 3500 series rack using one full-height front slot for the monitor module and one full-height rear slot for the I/O module. The 15-inch Advantech display mounts on a panel or rack shelf. Ensure proper grounding and cable connections for the VGA, RS232, and power inputs. The package typically includes the VGA display module, I/O module, 15-inch Advantech display (FPM-8151H) with 24 Vdc power supply, mounting hardware, and installation manual. Verify compatibility with 3500/22 Transient Data Interface (TDI) module and required firmware versions: 3500/94M Firmware 4.06 Rev. C, 3500/22 Firmware Rev 1.71, and software revisions as specified.

Purchasing Advice

When selecting the 3500/94M-06-00-01, confirm your rack configuration and environmental requirements. The Class I, Division 2 certification is critical for hazardous locations. Ensure your system includes the 3500/22 TDI module and compatible firmware. Petro Auto Tech offers genuine Bently Nevada modules with verified specifications and reliable support for your industrial automation needs.

Repair & Maintenance Tips

Regularly inspect the display for cracks or pixel damage. Clean the screen with a soft, dry cloth to avoid scratches. Check cable connections for wear or looseness. Store the module in a dry environment within the specified temperature range. Monitor the OK and TX/RX LEDs for proper operation. Avoid exposure to excessive humidity or condensation.

Frequently Asked Questions (FAQs)

Q: What is the power consumption of the 3500/94M-06-00-01?

A: The module consumes 4.6 watts max.

Q: What is the operating temperature range?

A: The operating temperature range is -20°C to 65°C (-22°F to 149°F).

Q: Does the module support hazardous area installations?

A: Yes, it has CSA/NRTL/C (Class I, Division 2) approval for hazardous locations.

Q: What display size is included with this model?

A: The 06 option includes a 15-inch display with panel mount.

Q: What firmware is required for the 3500/94M-06-00-01?

A: It requires 3500/94M Firmware 4.06 Rev. C and 3500/22 Firmware Rev 1.71 or newer.
