200151-60-02-02 | Bently Nevada 6.0 Meter Accelerometer Standard Cable

What Makes the 200151-60-02-02 Accelerometer Cable Essential for Vibration Monitoring?

When harsh industrial environments demand reliable signal transmission from vibration sensors, the 200151-60-02-02 from Bently Nevada provides a robust solution. This accelerometer standard cable, with a length of 6.0 meters, connects transducers to monitoring systems while maintaining signal integrity. Its construction includes a 4-conductor, 22 AWG design with braided shield and drain wire, ensuring consistent performance in demanding applications.

Key Features and Technical Specifications of the 200151-60-02-02

• Cable length: 6.0 meters (model -60).
• Armor option: 02 = Blue cable without armor.
• Coupling nut: 02 = Nylon coupling nut.
• Minimum bend radius: 63.5 mm (2.5 in).
• Operating temperature range: -20 °C to +100 °C (-4 °F to +212 °F).
• Construction: 4-conductor, 22 AWG with braided shield and drain wire (85% coverage, minimum), PVC outer jacket, nickel-plated coupling nuts.
• Seal: Connectors provide an IP67 seal to transducers and mating hardware; connectors are molded to the cable.
• DC4 electrical insulating compound in connectors provides additional protection against moisture during thermal shock.
• Temperature range for DC4 compound: -55 °C to +121 °C (-67 °F to +250 °F); cure time: 24 hours.

A distinctive feature is the IP67 seal at the connectors, which protects against dust and water ingress, making the 200151-60-02-02 suitable for wet or washdown environments. The nylon coupling nut offers corrosion resistance while ensuring a secure connection.

Real-World Applications for the Bently Nevada 200151-60-02-02

In industrial settings such as oil refineries, power plants, and manufacturing facilities, the 200151-60-02-02 cable connects accelerometers to monitoring systems for continuous vibration analysis. Its rugged construction withstands temperature extremes from -20 °C to +100 °C, making it ideal for outdoor or high-heat areas. The IP67 seal ensures reliable operation even in dusty or humid conditions, reducing the risk of signal degradation.

Installation and Setup Guidance

When installing the 200151-60-02-02, ensure the cable does not exceed its minimum bend radius of 63.5 mm to avoid internal damage. The connectors are molded to the cable, so avoid pulling on the cable body when connecting or disconnecting. For installations below -20 °C, avoid flexing the cable to prevent damage. Always verify that the coupling nut is tightened securely to maintain the IP67 seal.

Maintenance and Reliability Tips

Periodically inspect the 200151-60-02-02 cable for cuts, abrasions, or signs of wear on the PVC jacket. Check the coupling nuts for corrosion or looseness, especially in harsh environments. The DC4 insulating compound inside the connectors should be allowed to cure for 24 hours after application to ensure full moisture protection. Regular inspection helps extend cable life and maintain signal quality.

Frequently Asked Questions about the 200151-60-02-02

Q: What is the cable length of the 200151-60-02-02?

A: The cable length is 6.0 meters, as indicated by the -60 in the model number.

Q: What type of coupling nut does this cable use?

A: It uses a nylon coupling nut (option 02), which provides corrosion resistance and a secure connection.

Q: Is the cable armored?

A: No, the armor option 02 indicates blue cable without armor.

Q: What is the operating temperature range?

A: The cable operates from -20 °C to +100 °C (-4 °F to +212 °F).

Q: Does the connector provide environmental sealing?

A: Yes, the connectors provide an IP67 seal to transducers and mating hardware, protecting against dust and water ingress.

Product Support and Availability

The 200151-60-02-02 is in stock and ready to ship from Petro Auto Tech, your trusted source for industrial automation parts. Contact our team for pricing and availability.
