Allen-Bradley 1756-M16SE ControlLogix 16 Axis SERCOS Servo Module

Product Overview

The Allen-Bradley 1756-M16SE is a high-performance servo module. It belongs to the ControlLogix series. This module supports up to 16 axes. It uses the SERCOS interface for communication. The data rate is 4 Mb/s or 8 Mb/s. It draws 1.2 amps at 5.1 Volts. The continuous power dissipation is 6.2 Watts. This module is ideal for complex motion applications. It ensures reliable and synchronized control.

Application Scenarios

This module works well in packaging machines. It also suits printing presses and assembly lines. You can use it in material handling systems. It excels in high-speed pick-and-place operations. The module controls multiple axes with precision. It integrates easily into existing ControlLogix systems. This makes it a versatile choice for automation.

Technical Specifications

The isolation voltage is 50 Volts. The backplane current at 5 Volts is 760 milliamps. At 24 Volts, it is 2.5 milliamps. The thermal dissipation is 21.2 BTU-hour. Each module supports up to 16 axes. The controller can manage up to 32 axes. The enclosure type is None. The UPC is 10612598296986. These specifications ensure stable operation.

Installation & Maintenance Guide

Install the module in a ControlLogix chassis. Ensure the backplane is clean and secure. Use proper grounding techniques. Check the data rate settings before use. The module requires minimal maintenance. Keep the area free from dust and moisture. Follow the user manual for detailed steps. Use only approved cables for connections.

Packing List

The package includes one Allen-Bradley 1756-M16SE module. It does not include cables or software. The module is new and in original packaging. We ship via Fedex, UPS, or DHL. All items are carefully packed for safe delivery. Contact us for any missing parts.
