Allen-Bradley 1756-RIO Remote I/O Adapter Module ControlLogix

Product Overview

The Allen-Bradley 1756-RIO is a Remote I/O Adapter Module. It works with ControlLogix systems. This module connects remote I/O racks. It uses a standard chassis. The module operates from 32 to 140 Fahrenheit. It draws 450 milliamps from the 5.1 Volt DC backplane. This adapter is a key part of many automation setups.

Application Scenarios

Use the 1756-RIO in industrial control systems. It links remote sensors and actuators. It works well in manufacturing plants. It is ideal for process control. Use it in material handling systems. It suits oil and gas applications. It also fits water treatment facilities. The module handles harsh environments. It provides stable communication. It reduces wiring costs.

Technical Specifications

This module has clear specs. It uses 20 AWG wire. Its max power dissipation is 2.5 Watts. The isolation voltage is 50 Volts continuous. It draws 5 milliamps from the 24 Volt DC backplane. It draws 450 milliamps from the 5.1 Volt DC backplane. The module fits in a chassis. It supports these chassis: 1756-A4, 1756-A7, 1756-A10, 1756-A13, and 1756-A17. It works with standard power supplies. It also works with redundant power supplies.

Installation & Maintenance Guide

Install the module in a ControlLogix chassis. Use standard power supplies. Ensure the chassis is powered off. Insert the module firmly. Secure it with the locking mechanism. Connect the remote I/O cable. Use proper wire size. Check the backplane current draw. Keep the module clean. Do not block airflow. Replace failed modules quickly.

Packing List

The package includes one Allen-Bradley 1756-RIO module. It does not include a power supply. It does not include a chassis. It does not include cables. The module is new in box. We ship via Fedex, UPS, or DHL.
