Allen-Bradley 22F-RF6P0-AL EMC Filter Kit for PowerFlex 4M

Product Overview

The Allen-Bradley 22F-RF6P0-AL is an EMC filter kit. It is designed for PowerFlex 4M drives. This L type filter works with 480 V AC systems. It operates at 50 or 60 Hz. The kit supports 0.4 to 1.5 kW motors. It also handles 0.5 to 2 HP motors. This filter reduces electromagnetic interference. It is ideal for long cable lengths. The unit uses a panel mount design. Its enclosure rating is IP20. It meets UL and NEMA Type Open standards. This filter ensures clean power delivery. It protects sensitive equipment from noise. The 22F-RF6P0-AL is a reliable choice for industrial use.

Application Scenarios

This filter works best with variable frequency drives. Use it in manufacturing plants. It is great for conveyor systems. It also suits pump and fan applications. The filter handles long motor cables. It reduces radiated emissions. This helps meet EMC regulations. Use it in HVAC systems. It works well in material handling. The filter is also good for packaging machines. It supports three-phase systems. The voltage range is 380 to 480 V AC. This makes it versatile for global use. Always pair it with a PowerFlex 4M drive.

Technical Specifications

The filter is a L type design. It supports 6 A continuous current. The input voltage is 480 V AC. It works with three-phase power. The frequency range is 50 to 60 Hz. The power rating is 0.4 to 1.5 kW. It also supports 0.5 to 2 HP. The unit mounts on a panel. Its enclosure is IP20. It has a NEMA Type Open rating. The filter reduces EMI for long cables. It weighs about 1.5 kg. The operating temperature is standard industrial range. It includes mounting hardware.

Installation & Maintenance Guide

Mount the filter on a flat panel. Use the included hardware. Connect the input to the drive. Follow the wiring diagram. Keep cables short inside the cabinet. Ensure proper grounding. Do not block ventilation. Check connections regularly. Clean the filter with a dry cloth. Do not use solvents. Test the system after installation. The filter needs no routine maintenance. Replace it if damaged. Always disconnect power before service.

Packing List

One EMC filter kit. Mounting screws included. Installation manual provided. No additional parts required. The kit is ready to install. Use FedEx, UPS, or DHL for shipping. The package is compact and secure.
