Analog Terminal Board Yokogawa SEA4D-06 16 Channels SIL3

Product Overview

The Yokogawa SEA4D-06 is a robust analog terminal board. It offers 16 channels x 2 for reliable signal connection. This board uses M4 screw terminals for secure wiring. It meets SIL3 safety standards for critical processes. The board works with SAI143, SAV144, and SAI533 modules. Its design ensures stable performance in harsh environments. The SEA4D-06 supports high-density I/O configurations. It simplifies field wiring and reduces installation time. The board provides excellent electrical isolation for signal integrity.

Application Scenarios

This terminal board fits many industrial control systems. Use it in chemical plants for process monitoring. It works well in oil and gas refineries. The board supports power generation facilities. It is ideal for water treatment plants. Use it in manufacturing automation lines. The SEA4D-06 handles temperature and pressure signals. It connects analog input and output devices. The board suits safety-critical applications. It performs reliably in high-vibration areas.

Technical Specifications

The board has 16 channels x 2 for dual signal paths. It uses M4 screw terminals for easy connection. Insulation resistance is 100 MΩ minimum at 500 V DC. Withstand voltage is 500 V AC for one minute. The product weighs 2.5 kg. Dimensions are 4.5 kg for the package. The board carries SIL3 certification. It works with SAI143, SAV144, and SAI533 modules. These specs ensure safe and accurate signal transfer. The board meets strict industrial standards.

Installation & Maintenance Guide

Mount the board on a standard DIN rail. Use M4 screws for all wire connections. Ensure proper torque for secure contact. Check insulation resistance before power-up. Perform a withstand voltage test annually. Keep the board free from dust and moisture. Use shielded cables for noisy environments. The SEA4D-06 requires minimal maintenance. Inspect terminals for corrosion regularly. Replace the board if damage is visible. Follow Yokogawa guidelines for best results. Use Fedex, UPS, or DHL for shipping.

Packing List

The package includes one Yokogawa SEA4D-06 terminal board. It comes with a set of M4 screws. A user manual is provided for installation. The board is packed in anti-static material. No additional accessories are included. Ensure all items are present before use. Contact support if parts are missing. Use Fedex, UPS, or DHL for safe delivery.
