PowerFlex 4M EMC Filter Kit 22F-RF6P0-AS Line Filter

Product Overview

The Allen-Bradley 22F-RF6P0-AS is an EMC filter kit. It works with PowerFlex 4M drives. This line filter reduces electrical noise. It supports 3-phase, 200-240V AC power. The current rating is 6.0 amps. This kit is for short cable lengths. It ensures your drive meets EMC standards. Use it for reliable motor control.

Application Scenarios

Use this filter in industrial automation. It fits conveyor systems and pumps. It works well for fans and compressors. Use it in packaging machines. It helps in material handling. The filter is ideal for tight spaces. It keeps your system clean from interference.

Technical Specifications

This is a line filter kit. It has a three-phase input. The voltage range is 200-240V AC. It handles 6.0 amps of current. The frequency is 50/60 Hz. It supports 0.4 to 1.5 kW drives. The filter type is short cable. It reduces electromagnetic interference.

Installation & Maintenance Guide

Mount the filter near the drive. Use proper grounding techniques. Connect input power to the filter. Then connect filter output to the drive. Keep cables short for best results. Check connections regularly. Ensure no dust builds up. Replace if damaged.

Packing List

One EMC filter kit. Includes mounting hardware. Includes installation instructions. This kit comes in a single box.
