ControlLogix 5580 Controller 1756-L82E-NSE by Allen-Bradley

Product Overview

The Allen-Bradley 1756-L82E-NSE is a powerful industrial controller from the ControlLogix 5580 series. It features 3 MB of user memory and 2 GB of optional nonvolatile memory. This model includes a non-removable embedded energy storage module. It supports 32 controller tasks and up to 1000 programs per task. The controller draws 1.2 A at 5.1V DC and 5 mA at 1.2V DC. Its thermal dissipation rating is 21.2 BTU per hour. This unit weighs about 0.394 kilograms.

The 1756-L82E-NSE comes with integral communication ports. It has one USB port and one embedded Ethernet port. It also supports networks like SynchLink, Remote I/O, DeviceNet, ControlNet, and EtherNet. You can program it using Function Block Diagram, Structured Text, Relay Ladder Logic, or Sequential Function Chart.

Application Scenarios

This controller works well in discrete and process manufacturing. It handles complex automation tasks in assembly lines and packaging systems. It also fits in material handling and robotic control applications. The 1756-L82E-NSE is ideal for high-speed production environments. It manages multiple tasks and programs without performance loss.

Technical Specifications

The controller has a vibration rating of 2 g at 10 to 500 Hertz. It can handle a relative humidity range of 5 to 95 percent without condensation. Its maximum operating shock rating is 30 g. The non-operating shock rating is also 30 g. The isolation voltage rating is 50 Volts continuous for basic insulation. This applies to the Ethernet port to backplane, USB port to backplane, and USB port to Ethernet port.

It supports unlimited local I/O event triggers. The controller uses a 5.1V DC power supply with a maximum draw of 1.2 Amps. It also draws 5 milliamps at 1.2 Volts DC. The 1756-L82E-NSE offers robust performance for demanding industrial tasks.

Installation & Maintenance Guide

Install the controller in a clean, dry location. Ensure proper ventilation to avoid overheating. Mount it securely on a DIN rail or panel. Connect power according to the voltage specifications. Use the embedded Ethernet port for network setup. For maintenance, check the energy storage module periodically. Replace it if needed following the user manual. Keep the firmware updated for best performance.

Packing List

Each unit includes one Allen-Bradley 1756-L82E-NSE Controller. It comes with a quick start guide. No cables or software are included. Shipping is via FedEx, UPS, or DHL.
