General Electric IS200EPCTG1A Exciter PT/CT Terminal Board

Product Overview

The IS200EPCTG1A is an Exciter PT/CT Terminal Board. General Electric makes it for the EX2100 series. This board receives PT and CT feedbacks. It works as an input/output terminal board. The board size is 23.8 cm high and 8.6 cm. It weighs only 0.45 kg. The operating temperature range is -30 to 65 degrees Celsius. It uses a 28 V dc power supply. This board is in stock and ready to ship.

Application Scenarios

This board works in industrial excitation systems. It connects to potential transformers and current transformers. The IS200EPCTG1A processes feedback signals. It helps control generator excitation. You can use it in power plants. It also works in heavy industrial settings. The board handles analog inputs from 0-10 V or 4-20 mA. Cable length can reach up to 1000 feet. It accepts wire gage up to 10 AWG.

Technical Specifications

The board has three terminal blocks. The PT/CT input burdens are less than 1 VA. The board type is an input/output terminal board. The functional acronym is EPCT. It stands for Exciter PT/CT. The board receives feedback from PT and CT sources. The power supply voltage is 28 V dc. The board size is 23.8 cm high by 8.6 cm. It weighs 0.45 kg. The operating temperature range is -30 to 65 degrees Celsius.

Installation & Maintenance Guide

Install the board in a clean and dry area. Ensure the power is off before connecting wires. Use wire gage up to 10 AWG. Keep cable length under 1000 feet. Check all terminal blocks for tight connections. Use analog input signals of 0-10 V or 4-20 mA. Follow the manual GEI-100459 for full details. Perform regular visual inspections. Replace the board if you see damage.

Packing List

You will receive one Exciter PT/CT Terminal Board. The board is the IS200EPCTG1A model. It comes in antistatic packaging. No additional cables are included. The package includes a packing slip. We ship via Fedex, UPS, or DHL. The country of origin is the USA.
