PLC Controller Allen-Bradley 1756-L83E-NSE ControlLogix 5580

Product Overview

The 1756-L83E-NSE is a powerful controller from Allen-Bradley. It belongs to the ControlLogix 5580 series. This unit features a no stored energy design for enhanced safety. It offers 3 MB of user memory for complex logic. The controller supports 32 tasks and 1000 programs per task. This allows for highly structured application development. It draws a minimum of 5 mA at 1.2V DC. Its maximum draw is 1.2 A at 5.1V DC. An optional 2 GB nonvolatile memory is available. This model is ideal for demanding industrial environments.

Application Scenarios

Engineers use this controller for large-scale machine control. It works well in discrete manufacturing and process applications. The 1756-L83E-NSE fits into packaging, material handling, and assembly lines. It also supports motion control and safety applications. Its high task count suits multi-machine coordination. The controller excels in data-intensive and high-speed operations. It is a standard choice for modern automation systems.

Technical Specifications

User memory is 3 MB for logic and data. Nonvolatile memory is optional at 2 GB. The controller supports 32 tasks. Each task can hold up to 1000 programs. Minimum current draw is 5 mA at 1.2V DC. Maximum current draw is 1.2 A at 5.1V DC. The product type is a no stored energy controller. This reduces risk during maintenance. The unit is part of the ControlLogix 5580 product line.

Installation & Maintenance Guide

Mount the 1756-L83E-NSE in a ControlLogix chassis. Ensure proper power supply connection to the backplane. Use a 5.1V DC power source for maximum draw. Do not exceed the rated current limits. The no stored energy design simplifies handling. Remove power before inserting or removing the module. Use standard Rockwell software for configuration. Keep the module in a clean, dry environment.

Packing List

One 1756-L83E-NSE controller module. No additional accessories are included. The unit is packaged in an anti-static bag. It is shipped in a protective box. Shipping options include Fedex, UPS, or DHL.
