200155-17-05 | Bently Nevada Low Frequency Trendmaster Pro Accelerometer

Introduction to the Bently Nevada 200155-17-05

When monitoring fin-fan and slow rotating shafts, the 200155-17-05 from Bently Nevada provides reliable low-frequency vibration data. This Low Frequency Trendmaster Pro Accelerometer is designed for use with ProTIM Option Low Frequency Acceleration-to-Velocity channel type (-05). It offers a sensitivity of 10.2 mV/(m/s²) (100 mV/g) at 80 Hz, making it suitable for demanding industrial environments.

Key Features and Technical Specifications

• Sensitivity: 10.2 mV/(m/s²) (100 mV/g) at 80 Hz, ±12%.
• Measurement Range: ±196 m/s² (±20 g) peak.
• Frequency Range: 1.5 to 10,000 Hz (90 to 600,000 cpm), referenced to 80 Hz (±10%).
• Mounted Resonant Frequency: >20 kHz (>1200 kcpm).
• Amplitude Linearity: ±2% (1 to 10 g pk).
• Transverse Sensitivity: ≤7%.
• Settling Time: ≤2000 ms (within 5% of bias).
• Excitation Voltage: 4.7 to 5.5 Vdc.
• Quiescent Current: <800 µA.
• Output Bias Voltage: +2.5 ± 0.23 Vdc.
• Temperature Range: -40 ºC to +105 ºC (-40 ºF to +221 ºF).
• Axial Shock Limit: 49,050 m/s² pk (5,000 g pk).
• Sealing: Hermetic, 5x10⁻⁸ atm•cc/s (3.1x10⁻⁹ atm•in³/s) maximum.
• Relative Humidity: 100% relative, condensing, non-submerged.
• Size: 17.5 mm x 45.7 mm (11/16 in x 1.8 in).
• Weight: 58 g (2.0 oz), typical.
• Mounting Thread: 3/8-24 female.
• Mounting Torque: 2.7 to 6.8 N•m (2 to 5 ft•lbf).
• Sensing Element: Ceramic, shear geometry.
• Housing Material: 316L stainless steel.

Applications and Use Cases

The 200155-17-05 excels in low-frequency vibration monitoring for fin-fan and slow rotating shafts. It is ideal for applications where precise acceleration measurement is critical, such as in cooling towers or large rotating equipment. Its rugged design ensures reliable operation in harsh industrial environments.

Installation and Setup

Mount the accelerometer using the 3/8-24 female thread with a torque of 2.7 to 6.8 N•m (2 to 5 ft•lbf). The mounting stud option is 17 3/8-24 to 3/8-16 UNC 1-3/8 inch hex plate stud. Ensure the base is clean and flat for optimal coupling. After installation, allow 24 hours cure time before full operation.

Maintenance and Reliability

Regular inspection of the 200155-17-05 helps maintain accuracy. Check for physical damage or contamination. The hermetically sealed design protects against moisture and dust. Follow manufacturer guidelines for periodic verification of sensitivity and bias voltage.

Compatibility and Integration

This accelerometer works with ProTIM Option Low Frequency Acceleration-to-Velocity channel type (-05). It is part of the Bently Nevada Trendmaster Pro family, ensuring seamless integration with existing monitoring systems. The multiple approvals (CSA, ATEX, and IECEx) expand its global applicability.

Troubleshooting and Common Issues

If output bias voltage deviates from +2.5 ± 0.23 Vdc, check excitation voltage (4.7 to 5.5 Vdc) and quiescent current (2000 ms) may indicate improper mounting or environmental stress. Verify cable connections and sensor grounding.

FAQ about 200155-17-05

What is the sensitivity of the 200155-17-05?

The sensitivity is 10.2 mV/(m/s²) (100 mV/g) at 80 Hz, ±12%.

What is the measurement range of this accelerometer?

The measurement range is ±196 m/s² (±20 g) peak.

What temperature range can the 200155-17-05 withstand?

It operates from -40 ºC to +105 ºC (-40 ºF to +221 ºF).

What mounting thread does the 200155-17-05 use?

It uses a 3/8-24 female thread with a mounting torque of 2.7 to 6.8 N•m (2 to 5 ft•lbf).

Product Support and Availability

The 200155-17-05 is in stock and ready to ship from Petro Auto Tech. Contact our team for pricing and lead times. We provide fast, reliable service for industrial automation parts.
