PLC Controller GE IS415UCCCH4A Mark VIe Single Slot Board

Product Overview

The GE IS415UCCCH4A is a single-slot controller board. It belongs to the Mark VIe Series. This board is for Distributed Control Systems (DCS). It uses a CompactPCI form factor. The board runs QNX Neutrino OS. This OS is real-time and multitasking. It ensures high speed and high reliability. The board connects to I/O packs via onboard networks. It mounts inside a CPCI enclosure. The I/O networks are private Ethernet systems. They support only controllers and I/O packs. This design boosts security and performance.

Application Scenarios

This controller works in industrial automation. It controls turbines and machinery. It manages power generation systems. It also handles process control. The board links to HMIs and other devices. It uses the Unit Data Highway (UDH). This is an Ethernet connection. It also has I/O network ports. These are labeled R, S, and T. A COM1 port uses RS-232C for setup. The board fits in harsh environments. It supports real-time data exchange.

Technical Specifications

The IS415UCCCH4A is a 6U high board. It is a single-board computer. It has five communication ports. One port is for UDH Ethernet. Three ports are for I/O networks. One port is for RS-232C serial. The OS is QNX Neutrino. The board uses CompactPCI standard. It connects to I/O packs directly. The I/O network is private Ethernet. It supports high-speed data transfer. The board is part of Mark VIe Series. It runs application code for DCS.

Installation & Maintenance Guide

Install the board in a CPCI enclosure. Ensure the slot is clean and dry. Align the board with the slot guides. Push firmly until it clicks. Connect the UDH Ethernet cable. Connect I/O network cables to R, S, T. Use COM1 for initial setup. Power on the system. Check LED indicators for status. Perform regular firmware updates. Keep the enclosure ventilated. Avoid dust and moisture. Use only approved cables.

Packing List

One GE IS415UCCCH4A controller board. One installation manual. No additional cables included. The board is anti-static packed. It ships in a secure box. Use Fedex, UPS, or DHL for shipping. Handle with care during transport.
