Servo Controller Module Allen-Bradley 1771-HSARS for PLC 5

Product Overview

The 1771-HSARS is a servo controller module from Allen-Bradley. It belongs to the PLC 5 series. This module comes with a standard plug-in memory cartridge. It uses a 120V fuse rating. The module fits into one slot of a Bulletin 1771 I/O chassis. It supports high-speed information processing for industrial control.

Application Scenarios

This module works well in large regulatory control tasks. It also suits sequential control applications. It needs processor coordination for specialized I/O requirements. Use it with PLC 5 controllers for automation. It handles high-speed data processing in industrial environments.

Technical Specifications

Manufacturer: Rockwell Automation. Brand: Allen-Bradley. Module type: IMC-120 AR. Fuse voltage: 120 Volts. Max input frequency: 250 Kilohertz differential. Outputs: +/- 10 Volt DC analog command. Slots: 2 per ES module. Update period: 2 ms per axis. Backplane current: 1.7 Amperes. Wiring arm: 1771-WA. Pulse capture time: 50-9.999 microseconds. Dimensions: 3.5 x 6.5 x 2.0 inches. Weight: 2.2 lbs. Operating temperature: 0-60°C. Humidity: 5-95% noncondensing. Shock: 30g operating.

Installation and Maintenance Guide

Install the module in a single slot of a 1771 I/O chassis. Use 1771-WA and 1771-WB wiring arms. These arms allow module replacement without disconnecting wiring. Ensure the environment is clean and dry. Avoid operating outside 0-60°C range. Keep humidity below 95% noncondensing. The module requires 1.7A backplane current. Verify the fuse rating of 120V.

Packing List

The package includes one 1771-HSARS servo controller module. It also includes the standard memory cartridge. Wiring arms 1771-WA and 1771-WB are included. No additional accessories are needed. Ship via FedEx, UPS, or DHL.
