Overview of the 1734-FPD Field Power Distributor
The 1734-FPD efficiently distributes field-side voltage to adjacent POINT I/O modules. It simplifies wiring and reduces installation complexity in control panels. This module accepts both AC and DC power supply inputs for versatile system integration.
1734-FPD handles a field power supply current of 10 amps reliably. It provides a continuous isolation voltage of 250 Volts for safe operation. This unit weighs just 0.12 kg for easy handling during installation.
Theme Option A: Product Procurement & Buyer Guide
System integrators choose the 1734-FPD to streamline field power distribution. It supports input voltages from 10-28.8V DC or 120-240V AC. This flexibility reduces the need for separate power supply modules.
Procurement managers value its robust mechanical design for industrial use. The module requires a wire size of 0.25-2.5 mm² (22-14 AWG). This allows easy connection to standard control panel wiring.
Application engineers benefit from its compact dimensions of 76.2 x 25.4 x 133.4 mm. Its open-style enclosure rating permits flexible mounting in various cabinets. The module can be mounted horizontally or vertically without performance loss.
Network connectivity includes ControlNet, DeviceNet, and EtherNet/IP via 1734 adapters. This ensures seamless integration into existing Rockwell Automation architectures. The operating temperature range is -20 to 55 °C for harsh environments.
This distributor has no power consumption or thermal dissipation. This unique feature keeps the system cool and reduces energy costs. The terminal base screw torque is 0.6 Nm (7 lb-in) for secure connections.
Theme Option E: Comparative Analysis & Alternative Matrix
The 1734-FPD focuses purely on field power distribution without logic functions. It contrasts with I/O modules that consume power and generate heat. This passive design improves overall system reliability significantly.
Its field power bus supply current of 10 A supports multiple downstream modules. Many competing power distributors offer lower current ratings for similar size. This makes the 1734-FPD suitable for high-density I/O configurations.
The continuous isolation voltage of 250 Volts exceeds typical 50V requirements. This provides an extra safety margin for industrial applications with voltage spikes. The unit also passes a 2600V DC dielectric test for 60 seconds.
Flexible input voltage acceptance sets it apart from fixed-voltage distributors. Engineers can use it in both 24V DC and 120V AC control systems. This versatility reduces inventory complexity for maintenance departments.
The removable terminal block (RTB) with handle simplifies field wiring changes. This feature speeds up commissioning and reduces downtime during replacements. Alternative distributors often require complete rewiring for module swaps.
