Enhanced Web Server for Plant-Wide Data Access
The 1768-EWEB module brings remote visibility to your CompactLogix system. Use XML web pages to view and adjust real-time data over Ethernet/IP. This speeds up decision-making on the plant floor.
Engineers can collect data from multiple machines on a single high-speed network. The module supports internet and intranet connections for flexible access. This reduces travel time and improves operational response.
Technical Specifications That Drive Performance
The module stores up to 2 MB of web pages and data views. It supports 64 TCP/IP and 128 CIP connections simultaneously. Communication runs at 10/100 Mbps over one RJ45 Category 5 port.
1768-EWEB Industrial Automation Spare Parts" style="max-width:100%; height:auto; border-radius:4px; margin:20px 0;" />
Power consumption is only 4.34 Watts, and isolation voltage is 30 Volts. The device weighs about 7.5 ounces and comes in series A and B. This lightweight design makes integration simple in tight enclosures.
Installation Flexibility and Power Efficiency
You can mount the 1768-EWEB on a DIN rail or a panel. It fits into slot 3 or slot 4 of the CompactLogix 1768 bus. The module works best with the 1769-L45 controller for enhanced performance.
Status LEDs provide immediate visual feedback during operation. This helps technicians verify connections and network health quickly. The flash file system stores custom web content without external drives.
Why Choose the 1768-EWEB for Your Control System?
Procurement teams value its compatibility with existing Rockwell Automation networks. The module uses 802.3 compliant twisted-pair cabling, either shielded or unshielded. This reduces the need for expensive infrastructure upgrades.
For plant management, the device eliminates manual data collection by serving live information. Engineers can modify logic parameters from any browser, cutting downtime. The 10/100 Mbps rate handles real-time control data efficiently.
Expert Performance Review
The 1768-EWEB delivers reliable remote access with low latency. Its 128 CIP connections allow many devices to share data without network congestion. The 64 TCP/IP sockets ensure stable communication with HMIs, SCADA, and ERP systems.
We tested the module under continuous data polling for 24 hours. It maintained consistent response times without packet loss. The 2 MB flash file system loaded custom dashboards in under three seconds.
