The 1785-L20C15 ControlNet processor from Allen-Bradley merges local and remote I/O into one coherent system. It delivers high-speed control with a 0.5 ms average scan time. This module supports up to 512 forcible I/O points. It also provides 16 Kilowords of user memory with battery-backed RAM.
Product Procurement & Buyer Guide
Procurement engineers need a controller that handles demanding processes. The 1785-L20C15 supports up to 77 I/O chassis total. Among these, 12 can be universal remote I/O chassis. This flexibility reduces cabinet cost and wiring complexity. The backplane draws 2.7 A at 5 V typically. Ensure your power supply meets this load requirement.
Analog control is critical in many industries. This processor handles up to 512 analog I/O points. It also supports non-forcible analog I/O up to 32,000 points. Use the integrated ControlNet phase 1.5 interface for real-time data exchange. Note that you cannot mix ControlNet phases on the same network.
Memory backup uses a lithium battery and an EEPROM module option. The module supports scheduled and unscheduled peer-to-peer communication. Channel 1B acts as a remote I/O scanner or adapter. This design simplifies system architecture for maintenance teams.
The processor does not support extended local I/O chassis. Plan your chassis layout accordingly. The maximum total forcible I/O is 512 any mix or 384 complementary inputs and outputs. Use duplicate addresses for complementary mode. This specification helps you size your system accurately.
Deep-Dive Technical FAQ
Q1: What is the exact scan time for ControlNet I/O on the 1785-L20C15?
The average scan time per rack is 0.5 ms. This ensures deterministic control for high-speed applications.
Q2: Can I use this processor with existing DH+ networks?
Yes. Channel 1A is dedicated to DH+ communication. Channel 1B can also be configured as DH+. Maximum cable length is 3048 m at 57.6 kbits/s.
Q3: How do I program the controller?
Use the RS-232-C port (Channel 0) for DF1 or ASCII protocols. Use the DH+ port for remote programming. EEPROM modules (1785-ME16, -ME32, etc.) provide program backup.
Q4: Does the 1785-L20C15 support redundant ControlNet?
Yes. The two BNC connectors allow a redundant ControlNet link. This increases network reliability for critical processes.
Q5: What does the BATT indicator mean?
A red BATT light indicates the lithium backup battery is low. Replace the battery promptly to retain RAM contents.
