Introduction
Petro Auto Tech is pleased to offer the Allen-Bradley 2094-BC04-M03-S Kinetix 6000 Integrated Axis Module (IAM). This 400 Volt Class module combines a 28 kW converter and a 30 A inverter in a single unit. It provides high-performance motion control for demanding industrial automation applications. The module features Safe Torque Off (STO) functionality, enhancing operator safety and machine reliability. This product represents a significant advancement for systems requiring precise axis control and robust power management.
Key Features
The 2094-BC04-M03-S delivers a converter output of 28 kW and an inverter output current of 30 A. This power capacity supports high-torque and high-speed applications without compromising performance. The module operates with an input voltage range of 360-480V AC nominal, accommodating global industrial power standards. Its Safe Torque Off feature meets stringent safety requirements, allowing controlled shutdowns during emergencies. The integrated design simplifies wiring and reduces cabinet space compared to separate converter and inverter units. This consolidation lowers installation costs and improves system reliability.
Technical Specifications
The module accepts a three-phase AC input voltage from 324 to 528 Volts rms at 47-63 Hz. It draws a nominal input current of 44.0 Amperes and handles a maximum inrush current of 31.1 Amperes peak. For common bus follower configurations, the DC input voltage range is 458-747 Volts with a current of 41.5 Amperes. The internal shunt provides continuous power dissipation of 200 Watts and peak power of 22.5 Kilowatts, with a resistance of 28.75 Ohms. These specifications ensure stable operation under variable load conditions. The module achieves 97% efficiency, reducing energy waste and heat generation. It weighs 21.1 lbs (9.60 kg) and operates within a temperature range of 32-122°F (0-50°C).
Applications
The 2094-BC04-M03-S suits packaging machinery that requires precise indexing and high-speed motion. In material handling systems, it controls conveyor drives and robotic arms with consistent torque and speed. Assembly lines benefit from its ability to manage multiple axes synchronously, improving throughput and accuracy. The module's Safe Torque Off function makes it ideal for applications where operator safety is critical, such as press feeders or automated welding cells. Its robust design handles continuous duty cycles in harsh industrial environments.
Availability
Petro Auto Tech maintains a ready inventory of the 2094-BC04-M03-S for immediate shipment. We offer competitive pricing and fast delivery to support your project timelines. Our technical team provides application support and integration guidance. Contact Petro Auto Tech for pricing and availability. We also offer bulk discounts for volume orders and expedited shipping options.
Frequently Asked Questions
What is the lead time for the 2094-BC04-M03-S?
Petro Auto Tech stocks the 2094-BC04-M03-S in our warehouse, allowing same-day shipping for most orders. Typical lead time is 1-3 business days within the continental US. For international orders, shipping time varies by destination. We offer expedited shipping for urgent requirements. Contact our sales team for current lead times and delivery estimates.
Does the 2094-BC04-M03-S come with a warranty?
Yes, Petro Auto Tech provides a standard one-year warranty on the 2094-BC04-M03-S against manufacturing defects. The warranty covers repair or replacement of faulty units. Extended warranty options are available upon request. Our support team assists with warranty claims and technical issues. We ensure all products undergo functional testing before shipment to minimize potential problems.
What are the compatible systems for the 2094-BC04-M03-S?
The 2094-BC04-M03-S integrates with Allen-Bradley Kinetix 6000 drive systems and ControlLogix or CompactLogix controllers. It mounts on the leftmost position of the power rail and works with other Kinetix 6000 axis modules. The module supports Safe Torque Off via dedicated safety inputs. It requires compatible motor feedback connectors (catalog 2090-K6CK-D15M) and I/O interface kits (2090-K6CK-D44M or 2090-K6CK-D44S0), sold separately. For detailed system requirements, refer to the product manual.
