Product Summary
The Allen-Bradley 22F-D6P0N113 is a compact, 3.0 HP adjustable frequency AC drive. It belongs to the PowerFlex 4M series and delivers powerful machine-level speed control. This unit operates on a 380-480 VAC, three-phase input supply. It provides a robust output of 6.0 Amperes and 2.2 kW. Engineers value this drive for its space-saving design and ease of use.
Theme Option A: Product Procurement & Buyer Guide
Procurement managers need a drive that matches exact machine specs. The 22F-D6P0N113 delivers a precise 3.0 HP output at 2.2 kW. This drive accepts a global input voltage of 380-480 VAC. Its 6.2 Amp input current ensures stable power consumption. This model solves the pain point of limited panel space. Its compact A-frame design supports DIN rail mounting. The IP20 enclosure allows for installation in clean environments. This drive includes a built-in EMC filter for noise suppression. This feature reduces the need for external filtering components. The removable MOV allows safe use on ungrounded systems. This flexibility simplifies installation in older facilities with legacy wiring. The drive supports V/Hz control for basic speed regulation. This method provides reliable performance for conveyors and textile machines. The internal RS485 port enables Modbus RTU communication. This allows for easy integration into existing control networks. Application engineers benefit from the fixed keypad interface. This HIM module allows for immediate local monitoring and control. The relay pre-charge limits inrush current during power-up. This extends the lifespan of upstream contactors and circuit breakers. The adjustable PWM frequency up to 10 kHz ensures quiet motor operation. This is critical for noise-sensitive production areas.
Theme Option E: Comparative Analysis & Alternative Matrix
Choosing the correct drive requires understanding series differences. The 22F-D6P0N113 sits in the low-power range of the PowerFlex family. It is the smallest drive in the entire PowerFlex catalog. This model offers 5.2 kVA of input power capability. A higher-rated model in the series might offer 4.0 kW output. The 22F-D6P0N113 provides five 24 VDC discrete inputs. It also includes two analog inputs for speed reference signals. Competing models might offer more analog inputs for complex processes. This drive includes two Form C relay outputs for status indication. Larger drives often include more robust braking options. The 22F-D6P0N113 does not have an installed braking unit. Its 10 Amp fuse rating provides adequate branch circuit protection. The voltage range spans from 340 to 528 VAC. This wide range ensures stable operation during power fluctuations. The 22F-D6P0N113 utilizes Volts per Hertz control. More advanced PowerFlex models offer sensorless vector control. However, V/Hz control is perfectly suited for fan and pump applications. The feed-through wiring design of this unit simplifies retrofitting. This reduces installation time compared to older drive models.
Logistics & Standard Packaging Details
- One (1) Allen-Bradley PowerFlex 4M drive, model 22F-D6P0N113
- Standard keypad interface module (fixed)
- Integral EMC filter (installed)
- Quick-start reference guide
- Product documentation CD-ROM
Express delivery shipping is available via FedEx, UPS, and DHL.
