The GE DS200FSAAG2ABA is a Field Supply Gate Amplifier Board designed for the Mark V series Drive Control systems. This board amplifies signals from thyristor bridges to regulate field current in industrial motor drives. It operates within 0 to 50°C and measures 52 mm by 62 mm.
Key specifications include five onboard jumpers for configuration, a 10-pin terminal connector for field wiring, and two fuses for overcurrent protection. The board contains multiple test points for diagnostics. It uses transistors and integrated circuits to amplify low-level signals with additional current from the power source.
The DS200FSAAG2ABA is compatible with GE Mark V Drive Control systems and external field exciter modules. It integrates with SDCIG1, SDCI, DCFB, and SDCC boards. The board works with thyristor bridges in SCR power conversion units for J, K, L, M, G, C, and CX frame drives.
Installation requires mounting the board in the designated slot and connecting the 10-pin terminal. Ensure proper fuse ratings per the drive frame size. Use the manual GEH-6005 for wiring diagrams and jumper settings.
The board delivers reliable performance by converting shunt voltage into a frequency signal for precise field current control. It supports voltage-controlled oscillator circuits for accurate thyristor firing. The design ensures stable operation under industrial conditions.
For technical documentation, refer to manual GEH-6005. Petro Auto Tech offers in-stock availability and support. Contact our team for pricing and shipping details.
