170INT11003C | Schneider 500 kbit/s Communication Adapter

Introduction to the 170INT11003C Communication Adapter

When your Modicon Momentum network demands reliable, high-speed communication, the 170INT11003C from Schneider Electric is engineered to deliver. This communication adapter supports a transmission rate of 500 kbit/s, ensuring efficient data flow across your industrial systems. With a ring topology, it connects up to 254 devices per segment, providing the scalability needed for growing operations.

Part of the Modicon Momentum product line, the 170INT11003C is designed for seamless integration. Its fail-safe state and local LED signaling offer immediate status feedback, reducing downtime and simplifying troubleshooting. Whether you are upgrading an existing network or building a new one, this adapter provides a robust foundation.

Key Features and Technical Specifications

The 170INT11003C stands out with its impressive technical profile. Here are the core specifications that define its performance:

• Transmission Rate: 500 kbit/s for fast and consistent data transfer.
• Topology: Ring topology ensures redundant communication paths.
• Devices per Segment: Supports 0 to 254 devices, offering extensive network flexibility.
• Max Cable Distance: Up to 12,800 meters between devices, enabling wide-area installations.
• Electrical Connection: Two SUB-D 9 connectors for straightforward wiring.
• Protection Class: IP20 rated for internal installation environments.
• Electromagnetic Resistance: Withstands 10 V/m fields and electrostatic discharges of 4 kV/8 kV.

One distinctive feature is the fail-safe state, which maintains operation even under adverse conditions. This ensures that your network remains stable, minimizing the risk of data loss or system interruptions.

Industry Applications and Use Cases

The 170INT11003C is ideal for manufacturing plants, process control systems, and material handling operations where reliable communication is critical. Its ring topology and high device capacity make it suitable for large-scale automation networks. For example, in a bottling plant, the adapter can link multiple PLCs and sensors across a 12,800-meter cable run, ensuring real-time coordination. Additionally, its electromagnetic resistance allows deployment near motors and drives without performance degradation.

Installation and Setup Guidance

Installing the 170INT11003C is straightforward with its two SUB-D 9 connectors. Ensure that the ring topology is correctly configured to avoid communication loops. Mount the adapter in a clean, dry enclosure to maintain IP20 protection. Verify that cable distances do not exceed the 12,800-meter limit to guarantee signal integrity. Always follow Schneider Electric's installation manual for detailed wiring instructions.

Maintenance and Reliability Tips

To maximize the lifespan of the 170INT11003C, perform regular inspections of the connectors and cabling. Check the LED indicator for any fault signals, which can alert you to potential issues early. Because the adapter is IP20 rated, keep it free from dust and moisture. Periodic verification of the fail-safe functionality ensures that the adapter continues to operate correctly. Following these simple practices reduces unplanned downtime and extends service life.

Compatibility and Integration

The 170INT11003C is specifically designed for the Modicon Momentum series, ensuring seamless compatibility with existing Momentum I/O modules and controllers. Its ring topology integrates easily into redundant network architectures, enhancing system reliability. For mixed-vendor environments, the adapter's standard SUB-D 9 connections allow for straightforward integration with compatible devices.

Troubleshooting Common Issues

If communication errors occur, first verify that all devices are within the 254-device limit per segment. Check the cable distance—exceeding 12,800 meters can cause signal degradation. Ensure that the ring topology is not broken; a single open connection can disrupt the entire network. The LED indicator provides quick diagnostics: a steady green indicates normal operation, while flashing or red signals require attention. For persistent issues, consult the Schneider Electric technical support or contact Petro Auto Tech for assistance.

Frequently Asked Questions

Q: What is the maximum number of devices supported per segment?

A: The 170INT11003C supports up to 254 devices per segment, allowing for extensive network configurations.

Q: Can the 170INT11003C be used in a star topology?

A: No, the adapter is designed for ring topology only, which provides redundant communication paths.

Q: What is the maximum cable distance between devices?

A: The maximum cable distance is 12,800 meters, offering flexibility in large installations.

Q: Does the 170INT11003C have any electromagnetic immunity?

A: Yes, it resists electromagnetic fields up to 10 V/m and withstands electrostatic discharges of 4 kV/8 kV.

Product Support and Availability

The 170INT11003C is available from Petro Auto Tech, your trusted industrial automation parts supplier. We maintain a ready inventory to ensure quick delivery. For technical questions or ordering assistance, contact our team—we are here to support your automation needs.
