171CCC96030 | Schneider 50 MHz M1/M1E Processor Adapter Module

Introduction to the Schneider 171CCC96030

When your automation system demands reliable processing and seamless connectivity, the 171CCC96030 from Schneider Electric stands ready. This M1/M1E Processor Adapter Module is part of the Modicon Momentum family, engineered for industrial control environments where performance and dependability are non-negotiable.

With a clock frequency of 50 MHz, the 171CCC96030 handles complex logic with ease. It employs Ethernet as its communication protocol, ensuring robust data exchange across your network. Whether you are upgrading an existing line or designing a new system, this module offers the processing muscle you need.

Key Features and Technical Specifications

The 171CCC96030 is packed with features that make it a versatile choice for industrial automation. Below are the core specifications drawn directly from the datasheet:

• Clock frequency: 50 MHz
• Communication protocol: Ethernet
• Flash memory: 1 MB
• RAM capacity: 544 kB
• Rated supply voltage: 5.0 V DC ±5%
• Word length: 16 bit
• Register I/O processor capacity: 26,048 words (max)
• Discrete I/O processor capacity: 8192 I / 8192 O
• Scan time: 0.3 ms per kilobyte
• Operating temperature: 0 to 60 °C

One standout feature is the 0.3 ms per kilobyte scan time, which enables rapid data processing—critical for time-sensitive applications. Additionally, the module supports both flash and RAM memory, providing ample storage for your control programs and data.

Applications and Use Cases

The 171CCC96030 is designed for a wide range of industrial applications. Its Ethernet connectivity makes it ideal for networked control systems, while its processing capacity suits medium-to-large automation tasks. For example, in a manufacturing plant, this module can coordinate multiple I/O points, manage data logging, and communicate with supervisory systems—all in real time.

Moreover, the module’s ability to handle up to 26,048 register I/O words means it can support complex processes that require significant data manipulation. Its compact size and low power consumption (5 V DC) make it suitable for space-constrained panels.

Installation and Setup

Installing the 171CCC96030 is straightforward. The module is powered by the Momentum I/O base, so no separate power supply is needed. Simply mount the module onto the base, connect the Ethernet cable to the communication port, and wire the I/O bus as required.

Ensure the ambient temperature stays within 0 to 60 °C and that the environment is non-condensing. The module can operate at altitudes up to 2,000 meters, making it suitable for most industrial sites. Always follow Schneider’s installation guidelines to guarantee proper operation.

Maintenance and Reliability

Routine maintenance of the 171CCC96030 is minimal, but periodic inspection is recommended to ensure long-term reliability. Check the module’s seating on the I/O base, verify that all connections are secure, and confirm that the ventilation around the module is unobstructed.

The module is built to withstand industrial environments, with shock resistance up to 15 gn peak and vibration resistance of 1 gn. This robustness reduces the likelihood of failures, minimizing downtime and maintenance costs.

Compatibility and Integration

The 171CCC96030 integrates seamlessly with the Modicon Momentum automation platform. It supports Ethernet-based protocols, including Modbus TCP messaging and I/O scanning, which are essential for modern industrial networks.

Software compatibility includes Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, and ProWORX 32, giving you flexibility in programming environments. The module also features web services, such as a rack viewer and web page loader, for remote monitoring and configuration.

Common Questions About the 171CCC96030

Q: What is the maximum register I/O capacity of the 171CCC96030?

A: The module supports up to 26,048 words of register I/O, with a word length of 16 bits.

Q: Can the 171CCC96030 be used in high-vibration environments?

A: Yes, it is rated for vibration resistance of 1 gn and shock resistance up to 15 gn peak, making it suitable for demanding industrial settings.

Q: What communication ports are available on the 171CCC96030?

A: It has one Ethernet port and one I/O bus port, facilitating integration into control systems.

Q: What is the operating temperature range for this module?

A: It operates from 0 to 60 °C in non-condensing conditions, with storage from -40 to 85 °C.

Product Support and Availability

The 171CCC96030 is available from Petro Auto Tech, your trusted industrial automation parts supplier. We keep this module in stock and ready to ship, ensuring you get the components you need without delay. Contact our team for pricing and availability.
