177230-01-02-05 | Bently Nevada Seismic Transmitter 25.4 mm/s

Introduction to the Bently Nevada 177230-01-02-05

In the evolving landscape of industrial automation, the need for reliable vibration monitoring has never been greater. The 177230-01-02-05 from Bently Nevada addresses this demand with a robust seismic transmitter designed for continuous machinery protection. This device converts dynamic vibration into a standard 4-20 mA current loop signal, making it an essential component for PLC, DCS, and SCADA systems.

Built in the U.S.A., this transmitter combines precision sensing with rugged construction. Its 316L stainless steel case and hermetically sealed sensor ensure durability in harsh environments. With multiple approvals including CSA/NRTL/C and ATEX/IECEx, the 177230-01-02-05 meets stringent safety standards for industrial use.

Key Features and Technical Specifications

The 177230-01-02-05 offers a measurement range of 0 to 25.4 mm/s (0 to 1.0 in/s) peak, with a frequency response of 3 Hz to 1 kHz (±10%). Its output signal is a 4-20 mA current loop, proportional to peak vibration levels. The main loop sensitivity is 4 ± 0.3 mA for 0.0 mm/s and 20 ± 2 mA for full scale.

• Measurement Range: 0 – 25.4 mm/s (0 – 1.0 in/s)
• Frequency Response: 3 Hz to 1 kHz ± 10% (180 cpm to 60 kcpm ± 10%)
• Output Signal: 4 to 20 mA current loop from Pin A to Pin B
• Excitation Voltage: 12 to 30 Vdc (current limited to 40 mA)
• Operating Temperature: -40°C to +85°C (-40°F to +185°F)
• Relative Humidity: To 100% non-submerged
• Case Material: 316L stainless steel
• Connector: 3-pin MIL-C-5015, 316L stainless steel
• Mounting Hole: 1/4-28 UNF
• Weight: 0.131 kg (4.62 oz)

One distinctive feature is the mounted resonant frequency greater than 12 kHz, which minimizes the risk of resonance-induced errors in high-speed machinery. Additionally, transverse sensitivity is less than 5% of sensitivity, ensuring accurate axial measurements.

Applications and Use Cases

The 177230-01-02-05 is ideal for monitoring rotating equipment such as pumps, fans, and motors. In predictive maintenance programs, this transmitter provides continuous data that helps detect imbalance, misalignment, and bearing wear early. For example, in a chemical plant, the transmitter's 4-20 mA signal can be directly fed into a DCS for real-time trend analysis. Moreover, its rugged design makes it suitable for outdoor installations where humidity reaches 100% non-submerged.

Installation and Setup

Proper installation ensures accurate readings. The transmitter features a 1/4-28 UNF mounting hole and also supports M6 x 1 SI and M8 x 1.25 SI threads. Recommended mounting torque is 4 to 7 N-m (35.4 to 62.0 in-lbf). The connector wiring convention is straightforward: Pin A for 4-20 mA positive loop, Pin B for loop return, and Pin C for dynamic acceleration signal. Ensure the excitation voltage is within 12 to 30 Vdc, and the power supply is current limited to 40 mA.

Maintenance and Reliability

Routine inspection of the transmitter and its mounting is recommended to verify secure attachment and cable integrity. The hermetically sealed sensor protects against moisture, and the 316L stainless steel case resists corrosion. With a settling time of less than 15 seconds within 2% of final value, the device quickly stabilizes after power-up. Regular calibration checks per the manufacturer's manual help maintain accuracy over time.

Compatibility and Integration

This product is designed for use with PLCs, DCS, and SCADA systems that have internal power supplies typically current limited in the range of 30 mA to 35 mA. The 4-20 mA output is universally accepted by most industrial control systems, simplifying integration. The dynamic acceleration signal on Pin C provides additional diagnostic capability for advanced users.

Troubleshooting Common Issues

If the output signal is not within the expected 4-20 mA range, check the excitation voltage and loop wiring. Ensure the transmitter is mounted securely and not subjected to excessive shock. If readings are erratic, verify that the mounting torque is within 4 to 7 N-m. For persistent issues, consult the official Bently Nevada documentation or contact Petro Auto Tech for technical support.

Frequently Asked Questions

Q: What is the measurement range of the 177230-01-02-05?

A: The measurement range is 0 to 25.4 mm/s (0 to 1.0 in/s) peak.

Q: What output signal does this transmitter provide?

A: It provides a 4-20 mA current loop output proportional to peak vibration levels.

Q: What is the operating temperature range?

A: The operating temperature range is -40°C to +85°C (-40°F to +185°F).

Q: What approvals does the 177230-01-02-05 have?

A: It has multiple approvals including CSA/NRTL/C and ATEX/IECEx.

Q: What is the excitation voltage requirement?

A: The excitation voltage is 12 to 30 Vdc, with current limited to 40 mA.

Product Support and Availability

At Petro Auto Tech, we stock the Bently Nevada 177230-01-02-05 seismic transmitter. Our team can assist with product selection and technical inquiries. Contact us to confirm availability and lead times. We are committed to providing genuine industrial automation parts.
