190501-07-00-01 | Bently Nevada Velomitor CT Velocity Transducer

Introduction to the Bently Nevada 190501-07-00-01 Velomitor CT

When rotating machinery begins to vibrate unexpectedly, the consequences can be costly. The 190501-07-00-01 from Bently Nevada provides a reliable solution for continuous velocity monitoring. This Velomitor CT velocity transducer is engineered for harsh industrial environments, offering precise measurements that help prevent unplanned downtime.

With a sensitivity of 3.94 mV/mm/s (±5%), this transducer captures even subtle changes in machinery vibration. Its frequency response spans 3.0 Hz to 900 Hz (±1.0 dB), making it suitable for a wide range of rotating equipment. The 190501-07-00-01 is part of Bently Nevada's trusted Velomitor CT series, known for durability and accuracy.

Key Features and Technical Specifications

The 190501-07-00-01 is built to perform under demanding conditions. Here are the core specifications that define its capabilities:

• Product Type: Velomitor CT Velocity Transducer
• Mounting Hardware: Plate Stud 3/8-in 24 to 3/8-in 24
• Connection Interface: MIL-C-5015
• Agency Approvals: CSA/NRTL/C (Class I, Division 1), ATEX/IECEx/CSA (Class I, Zone 0/1)
• Weight: 0.297 kg
• Operating Temperature: -40°C to +85°C
• Storage Temperature: -40°C to +100°C
• Shock Limit: 5000 g pk, maximum
• Humidity Limit: 100% condensing, non-submerged
• Case Material: 316L stainless steel

One standout feature is the output bias voltage of 10.1 Vdc ± 1.0 Vdc (Pin A referenced to Pin B). This stable bias ensures consistent signal transmission, which is critical for accurate data acquisition. Additionally, the dynamic output impedance is less than 400 Ω typical, allowing for reliable integration with monitoring systems.

Applications and Use Cases

The 190501-07-00-01 is ideal for monitoring vibration in pumps, motors, fans, and other rotating machinery. In petrochemical plants, where explosive atmospheres are a concern, its intrinsic safety certifications (Ex ia IIC T4) make it a safe choice for hazardous areas. The transducer's wide frequency response also suits high-speed equipment, such as turbines and compressors, ensuring that even high-frequency vibrations are captured accurately.

For maintenance teams, the 190501-07-00-01 helps detect early signs of bearing wear, misalignment, or imbalance. By providing real-time velocity data, it enables predictive maintenance strategies that reduce downtime and extend equipment life. Its robust construction, including a 316L stainless steel case, withstands corrosive environments, making it a long-term investment.

Installation and Setup

Proper installation is key to maximizing the performance of the 190501-07-00-01. The transducer mounts using a plate stud (3/8-in 24 thread) and can be oriented in any direction, offering flexibility in tight spaces. The MIL-C-5015 connection interface ensures a secure, weatherproof connection. For optimal signal integrity, keep cable lengths within 305 metres (1,000 ft.) using the specified cable (part number 02173006).

Mounting torque should be 4.5 N-m ± 0.6 N-m (40 in-lbf ± 5 in-lbf) to avoid damaging the transducer. Ensure the mounting surface is clean and flat to achieve the specified resonant frequency of 9 kHz minimum. For hazardous area installations, follow the provided installation drawing 167536 to maintain intrinsic safety.

Maintenance and Reliability

The 190501-07-00-01 requires minimal maintenance due to its solid-state design. However, periodic inspection is recommended to verify that the mounting remains secure and the connector is free from corrosion. The transducer's internal electronics are isolated from the case, reducing the risk of ground loops. Its temperature sensitivity is -8% to +5% typical over the operating range, ensuring stable performance across varying conditions.

By incorporating this transducer into a routine condition monitoring program, you can identify potential issues before they escalate. This proactive approach not only saves on repair costs but also extends the lifespan of your machinery, offering a strong return on investment.

Compatibility and Integration

The 190501-07-00-01 is designed to work with Bently Nevada monitoring systems and other compatible vibration monitoring equipment. Its output bias voltage and impedance characteristics align with standard data acquisition systems. The transducer's grounding scheme (internal electronics isolated from case) simplifies integration, reducing the risk of electrical interference.

For new installations, the transducer can be paired with Bently Nevada's 3500 series monitoring systems or similar platforms. Its MIL-C-5015 connector is a common interface, making replacement or upgrades straightforward.

FAQ about the 190501-07-00-01

Q: What is the sensitivity of the 190501-07-00-01?

A: The sensitivity is 3.94 mV/mm/s (100 mV/in/s) with a tolerance of ±5%.

Q: What are the agency approvals for this transducer?

A: It has CSA/NRTL/C (Class I, Division 1) and ATEX/IECEx/CSA (Class I, Zone 0/1) approvals, making it suitable for hazardous areas.

Q: What is the maximum cable length?

A: The maximum cable length is 305 metres (1,000 ft.) using cable part number 02173006, with no signal degradation.

Q: What is the operating temperature range?

A: The operating temperature range is -40°C to +85°C (-40°F to +185°F).

Q: Can the transducer be mounted in any orientation?

A: Yes, the mounting angle is any orientation, providing flexibility in installation.

Support and Availability

The 190501-07-00-01 is available from Petro Auto Tech, a trusted industrial automation parts supplier. We ensure genuine Bently Nevada products with prompt shipping. Contact Petro Auto Tech for current pricing and availability. Please verify the lifecycle status of this product before ordering, as it may be subject to discontinuation.
